Growatt inverter solar with charger solar kits 3000w 6000w 9000w 12000w generate electricity solar inverter
1. Competitive factory direct price, fast delivery.
2. The company has been focusing on R & D and production for 13 years, quality assurance
2. One-stop solution to the complete solar energy system can save your time and money.
3. Professional sales team, exported to more than 80 countries.
4. For large-scale solar power station projects, engineers can provide on-site guidance and installation services.
5. OEM service is acceptable and customized LOGO can be printed on the product.
Solar inverter Features
| Datasheet | SPF 3000TL LVM-24P | SPF 3000TL LVM-48P |
| Battery voltage | 24VDC | 48VDC |
| INVERTER OUTPUT | ||
| RATED POWER | 3000VA/ 3000W | 3000VA/ 3000W |
| Parallel Capability | Yes | Yes |
| AC Voltage Regulation (Battery Mode) | 120VAC ± 5% @ 50/60Hz |
120VAC ± 5% @ 50/60Hz |
| Surge Power | 6000VA | 6000VA |
| Efficiency (Peak) | 93% | 93% |
| Waveform | Pure sine wave | Pure sine wave |
| Transfer Time | 10 ms (For Personal Computers); 20 ms (For Home Appliances) | 10 ms (For Personal Computers); 20 ms (For Home Appliances) |
| SOLAR CHARGER | ||
| Maximum PV Array Power | 2000W | 4500W |
| MPPT Range @ Operating Voltage | 30VDC ~ 115VDC | 60VDC ~ 115VDC |
| Maximum PV Array Open Circuit Voltage | 145VDC | 145VDC |
| Maximum Solar Charge Current | 80A | 80A |
| Maximum Efficiency | 98% | 98% |
| Standby Power Consumption | 2 W | 2 W |
| AC CHARGER | ||
| Charge Current | 60A | 40A |
| AC Input Voltage | 120 VAC | 120 VAC |
| Selectable Voltage Range | 95-140 VAC(For Personal Computers); 65-140VAC(For Home Appliances) |
95-140 VAC(For Personal Computers); 65-140VAC(For Home Appliances) |
| Frequency Range | 50Hz/60Hz (Auto sensing) | 50Hz/60Hz (Auto sensing) |
| PHYSICAL | ||
| Dimension (D/W/H) in mm | 130/350/455 | 130/350/455 |
| Net Weight (kgs) | 11.5 | 11.5 |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | 5% to 95% Relative Humidity(Non-condensing) |
| Operating Temperature | 0°C - 55°C | 0°C - 55°C |
| Storage Temperature | -15°C - 60°C | -15°C - 60°C |
Solar inverter application
1. OEM&ODM services acceptable.
2. Lots of cooperated agent for shipping by sea or air.
Tips:
1. five year warranty, if it is a quality problem, we will provide parts for free.
2. If there is a problem with the machine during the warranty period, please contact the sales staff and we will provide remote assistance to the customer.
3. Beyond the warranty period, improper operation and man-made damage, we will still give help and support, and we will provide spare parts at the cost price.
4. According to the needs of customers, we can provide unconventional, but the cost may be slightly higher than that of traditional machines.
