Product Description
Features:Negative Ground, Max 170V PV inputDisplay daily generation and cumulative power generationSupport 4 charging options: Sealed, Gel, Flooded and User-definedThe tracking rate of maximum power is ≥99% and the maximum conversion rate is >98%Thecomponents are premium brand, the theoretical design life span is
>10 years, and the high temperature resistance is >105℃1、Display real-time power generation and current.2、Display the daily power generation curve and current curve.3、Chinese and English, multi-function LCD screen and operation menu.4、Display fault records, to facilitate customer troubleshooting in a timely manner5、Support lead-acid batteries, colloidal batteries and lithium batteries.6、Intelligent maximum power point tracking technology increases efficiency 25%~30%.7、Battery temperature sensor (BTS) automatically provides temperature compensation.8、Perfect protection function.9、 The latest MPPT algorithm is used to track the maximum power point of
solar power generation in real time. The charging efficiency is over
98.5 % and the tracking accuracy is over 99.73 %.10、Ultra-fast tracking speed, tracking 1 times per second. Specification:Rated current: 80A
Cut-off current: 83A
Maximum solar panel voltage:≤170V
Minimum solar panel voltage: 3V higher than the voltage of full-charged battery
(e.g. voltage of fully-charged 12V battery 14.6V+3V=17.6V)
Maximum solar panel power: Battery voltage * rated current = solar panel power (e.g. 12V*20A=240W)
Stabilized voltage precision:≤±1.5%Constant-voltage charging: 21.7V (18V) 43.5V (36V)
Float charging Recovery to charging: 19.9V (18V) 39.9V (36V)
Undervoltage protection Recovery to charging: 18V (18V) 39V (36V)
Undervoltage protection: 15.5V (18V) 31.5V (36V)For Lithium iron phosphate battery, Recovery to charging: 18.5V (18V) 37.5V (36V)For Lithium iron phosphate battery, Undervoltage protection: 15.5V (18V) 31.5V (36V)Input protection: Low voltage protection/high voltage protection/reverse polarity protection/short-circuit protection
Temperature protection: Stop work when the radiator temperature rises to 85°C.
Start conditions of the fan: When the radiator temperature hits 50°C/the charging current reaches 50% rated current
Environment humidity: 0-90%RH (without condensation)
Altitude: 0-3,000m
Working temperature: -20°C ~ +50°C
Storage temperature: -40°C ~ +70°C
Atmospheric pressure: 70-106KPa
Battery type: Lead-acid battery, Gel battery, Lithium iron phosphate batteryController Size: 29*24.5*10cm / 11.42*9.65*3.94inchSolar Controller weight: 4.85kgs / 10.59Pound Packing:
1*Solar Charge Controller
1* English instruction manual
