Product manual:
This product is a sine inverter board, simple battery and transformer can link the DC 12V, 24V, 36V, 48V,60V boost AC 220V. simple DIY set up, you can get a powerful set of solar power generation system. It can also become a powerful backup power or inverter. Output Power Properties and Household electricity same, even better than it is. So it is suitable for use with all appliances.
This product is a pure sine wave output, the input voltage changes will not affect the output waveform, did not have any adverse effects on electrical appliances. Please do not and Distortion
sine wave or square wave inverter comparison (too bad inverters, will slowly corrode your electrical appliances), Do
n
't understand friends, please log in google learning content.
High frequency high voltage pure sinusoidal inverters and low voltage low frequency pure sine inverter durable time comparison:
High frequency high voltage sine inverter durable for about 1 year
Low frequency low voltage sine inverter can be durable for 10 years (the product is low frequency low voltage)
This product is suitable with sound, electrical, air conditioning, television, computers, etc., and more durable than the high-frequency inverter, more suitable with inductive appliances.
Battery connected to the motherboard needs series 100A air switch, the motherboard needs Instant Energized.
Battery switch connection:
https://www.aliexpress.com/store/product/Free-shipping-1pcs-220V-100A-electrical-breaker-air-switch-circuit-breaker-mini-micro-off-sine-inverter/123900_32855773606.html?spm=2114.12010612.8148356.23.40ea315eVbGh3d
Products with overvoltage protection, heat protection, short circuit protection, low voltage protection, you can adjust the value you need. The default shipping is AC 220V 50HZ output.
Connection diagram(This product is only 1pcs motherboard, without any other accessories.)
Inductor:
(
The inductor is used to reduce the no-load current,
You can choose to use or not use
)
But, more magnetic leakage of the transformer, it is recommended to use.
If the machine is installed, the no-load current is large, it is necessary in the transformer low-side series inductance (inductance toroidal transformer must series connection).
Inductor:
https://www.aliexpress.com/store/product/Free-shipping-1pcs-47UH-140A-current-pure-sine-inverter-dedicated-power-inductor-sendust/123900_32855637489.html?spm=2114.12010612.8148356.52.f9997b12ZlTo3z
Please do not worry. For example: when you buy the product is selected 24V input, the maximum power is only 2000W. However, later want to use 48V input how to do? I am in the design of the circuit, has been considered for everyone. You only need to replace the corresponding transformer and replace the motherboard R1 and R2 resistor can achieve 48V input, can achieve 3500W output.
60V input, but also need to replace the output capacitor, I suggest you buy 60V input products directly.
12V Input: R1 = 10K; R2 = 0K
24V Input: R1 = 39K; R2 = 20K
36V Input: R1 = 68K; R2 = 47K
48V Input: R1 = 91K; R2 = 62K
60V Input: R1 = 110K; R2 = 91K
EGS002 driver board jumper Description:
JP1: When JP1 link, JP5 is disconnected, 60Hz output;
JP5: When JP5 link, JP1 is disconnected, 50Hz output;
JP2: When JP2 link, JP6 is disconnected, 3 seconds soft start;
JP6: When JP6 link, JP2 is disconnected, close the soft start.
Solve everyone DIY transformer
Transformers in parallel
Transformer in series
You can achieve the desired power transformers in parallel or in series.
Tips:
The above price is the price of the motherboard (including pure sine inverter board + 5UF capacitor), excluding local country customs duties.
Products are constantly updated, and the appearance of the product you receive may be slightly different, but the performance is the same. No further notice.
Hello everyone!
Too many recent customers to buy the motherboard, fear can not buy a suitable transformer, following a simple method of making suitable transformer.
Hello everyone! A lot of people in the use of the inverter, it is still not able to test the inverter is not a sine inverter. In fact, very simple to identify. The inverter output power to provide electricity for the audio system, pure sine wave inverter waveform clean, sound does not appear the current sound or noise, if the speaker sends the current sound or noise, it can determine the pure sine wave inverter the inverter is not clean or square wave inverter. You can test my products, and then give me feedback.
Product updates, component layout may be slightly different, no longer notice.
Note: This product is only suitable for electronic base customers to buy, once again stressed that the products have been checked by the factory, the normal use, there is no quality problems. The product does not have a warranty or a full refund. Please consult me as soon as possible when the product is not working properly. If you can not solve the problem, return shipping costs need to bear the buyer, at the same time, also need to bear the corresponding maintenance costs. When you receive the goods, please read my product description again. Otherwise it is very easy to man-made damage.
This product is a pure sine wave output, the input voltage changes will not affect the output waveform, did not have any adverse effects on electrical appliances. Please do not and Distortion
sine wave or square wave inverter comparison (too bad inverters, will slowly corrode your electrical appliances), Do
n
't understand friends, please log in google learning content.
High frequency high voltage pure sinusoidal inverters and low voltage low frequency pure sine inverter durable time comparison:
High frequency high voltage sine inverter durable for about 1 year
Low frequency low voltage sine inverter can be durable for 10 years (the product is low frequency low voltage)
This product is suitable with sound, electrical, air conditioning, television, computers, etc., and more durable than the high-frequency inverter, more suitable with inductive appliances.
This product requires the transformer is connected to work, before buying, please read the product description clearly, no electronic technology buyers please do not buy.
Suitable for all transformer
Board Size: 19cm x 11cm x 7.5cm Dimensions: 18.1cm x 9.1cm Board Weight: about 800g The power supply line is connected in series with a 100A air switch, the interface with the motherboard to solder welding firm, power transmission to instant, not intermittent, high power to increase heat dissipation. Power frequency pure sine wave inverter board, highly efficient and stable circuit, no-load current is small (<0.5A), battery voltage / overload / overheat protection, installed simple suitable for any transformer Before You Buy Note: 12V input, maximum power of 1000 AV (Real power) Peak:2000AV-3000AV 24V input, maximum power of 2000 AV (Real power) Peak:4000AV-6000AV 36V input, maximum power of 2800 AV (Real power) Peak:6000AV-9000AV 48V input, maximum power of 3500 AV (Real power) Peak:7000AV-11000AV 60V input, maximum power of 4000 AV (Real power) Peak:8000AV-13000AV Transformer requirements: 1000W transformer about 5 kg, 2000W transformer about 10 kg, 3000W transformer about 15 kg. Support transformer series or parallel. Tips: The product needs to connect the corresponding transformer to work. The product price does not include transformer 12V battery, Use about 7V transformer (220V to 6-8V) 24V battery, Use about 14V transformer (220V to 12-16V) 36V battery, Use about 20V transformer (220V to 18-22V) 48V battery, Use about 28V transformer (220V to 24-32V) 60V battery, Use about 32V transformer (220V to 31-39V) The product supports the transformer power is not limited, 50W or 2000W, or 5000W or 10000W or transformers in parallel or transformers in series. Transformer output corresponding voltage can work properly. The output power is determined by the input voltage and the transformer used has many relationships. For example: you use the 24V battery pack input, while using the 5000W transformer, the maximum output is only 2000W. Because you are using a 24V voltage input. However, if you use the transformer maximum power is only 300W, the maximum output power is only 300W, and the transformer heat is serious.
Battery connected to the motherboard needs series 100A air switch, the motherboard needs Instant Energized.
Battery switch connection:
https://www.aliexpress.com/store/product/Free-shipping-1pcs-220V-100A-electrical-breaker-air-switch-circuit-breaker-mini-micro-off-sine-inverter/123900_32855773606.html?spm=2114.12010612.8148356.23.40ea315eVbGh3d
Products with overvoltage protection, heat protection, short circuit protection, low voltage protection, you can adjust the value you need. The default shipping is AC 220V 50HZ output.
Connection diagram(This product is only 1pcs motherboard, without any other accessories.)
Inductor:
(
The inductor is used to reduce the no-load current,
You can choose to use or not use
)
But, more magnetic leakage of the transformer, it is recommended to use.
If the machine is installed, the no-load current is large, it is necessary in the transformer low-side series inductance (inductance toroidal transformer must series connection).
Inductor:
https://www.aliexpress.com/store/product/Free-shipping-1pcs-47UH-140A-current-pure-sine-inverter-dedicated-power-inductor-sendust/123900_32855637489.html?spm=2114.12010612.8148356.52.f9997b12ZlTo3z
Please do not worry. For example: when you buy the product is selected 24V input, the maximum power is only 2000W. However, later want to use 48V input how to do? I am in the design of the circuit, has been considered for everyone. You only need to replace the corresponding transformer and replace the motherboard R1 and R2 resistor can achieve 48V input, can achieve 3500W output.
60V input, but also need to replace the output capacitor, I suggest you buy 60V input products directly.
12V Input: R1 = 10K; R2 = 0K
24V Input: R1 = 39K; R2 = 20K
36V Input: R1 = 68K; R2 = 47K
48V Input: R1 = 91K; R2 = 62K
60V Input: R1 = 110K; R2 = 91K
EGS002 driver board jumper Description:
JP1: When JP1 link, JP5 is disconnected, 60Hz output;
JP5: When JP5 link, JP1 is disconnected, 50Hz output;
JP2: When JP2 link, JP6 is disconnected, 3 seconds soft start;
JP6: When JP6 link, JP2 is disconnected, close the soft start.
Frequency sine wave inverter board Function: 1. Low Battery Protection: When the battery voltage is lower than 10.5V each section, the inverter will turn off the inverter (this time without AC voltage output), the inverter is in standby mode. 2. Battery voltage protection: When the battery voltage is higher than 15V each section, the inverter will turn off the inverter into standby mode. 3. The battery is OK to start automatically: When the battery voltage protection, when the solar wind or charge the battery charged to 13V each section, the inverter automatically start output AC voltage supply to the load. When the battery voltage protection 15V overvoltage protection and then return to each section, the inverter automatically start. 4. The temperature-controlled fan, and overtemperature protection: The inverter does not turn the fan is working properly, when the temperature is too high, fan automatic operation, when the temperature drops, the fan automatically stops running. When the fan is damaged, the temperature is too high, the inverter will turn off the inverter into standby mode. When the temperature drops, and automatically starts the inverter output AC. 5. Impact and short circuit protection: The inverter apparatus sometimes real hardware Zhu Bo-limiting flow protection, and software delay (400mS) short-circuit protection plus frequency isolation transformer. Improve product reliability impact resistance of the product. Recently, many buyers to buy my products are worried that canlsquot find a suitable transformer, in fact, the transformer is easy to match, the following circuit diagram can use low-power transformers to high-power transformers.
Solve everyone DIY transformer
Transformers in parallel
Transformer in series
You can achieve the desired power transformers in parallel or in series.
Tips:
The above price is the price of the motherboard (including pure sine inverter board + 5UF capacitor), excluding local country customs duties.
Products are constantly updated, and the appearance of the product you receive may be slightly different, but the performance is the same. No further notice.
Hello everyone!
Too many recent customers to buy the motherboard, fear can not buy a suitable transformer, following a simple method of making suitable transformer.
Hello everyone! A lot of people in the use of the inverter, it is still not able to test the inverter is not a sine inverter. In fact, very simple to identify. The inverter output power to provide electricity for the audio system, pure sine wave inverter waveform clean, sound does not appear the current sound or noise, if the speaker sends the current sound or noise, it can determine the pure sine wave inverter the inverter is not clean or square wave inverter. You can test my products, and then give me feedback.
Product updates, component layout may be slightly different, no longer notice.
Note: This product is only suitable for electronic base customers to buy, once again stressed that the products have been checked by the factory, the normal use, there is no quality problems. The product does not have a warranty or a full refund. Please consult me as soon as possible when the product is not working properly. If you can not solve the problem, return shipping costs need to bear the buyer, at the same time, also need to bear the corresponding maintenance costs. When you receive the goods, please read my product description again. Otherwise it is very easy to man-made damage.
