Product description:
1. Intelligent and convenient: The solar charging controller is controlled by a single chip computer, which has the advantages of intelligence, strong adaptability and reliable functions
2. Long life battery: the solar charging controller adopts high-precision temperature detection and compensation circuit, so the battery life is longer
3.12V 24V 48V: The solar charging controller has 12V 24V 48V system voltage automatic identification and three-level battery power display. Fine structure design and circuit design
Product specification:
Project type: solar charging controller
Material: ABS
Product size: about 192 * 162 * 60mm/7.55 * 6.37 * 2.36 inches
indicator light:
Solar energy: charging state indicator, steady on indicates charging, and flashing indicates floating charging.
Load: discharge status indicator. When the load indicator is on, it indicates that the battery is allowed to output, but it does not indicate whether there is actual output current.
Battery: battery level indicator
Rated charging current: 100A
System voltage: 12V 24V 48V automatic adaptation
Overload and short circuit protection: ≥ 1.5 times of rated current
No load loss:10mA
Operating temperature: - 35 ℃ to+55 ℃
Package contents:
1 * Solar charging controller
