| Solar Home System——ZSPD0030-0060 Technical specification sheet | ||||||
| Product type | ZSPD0030 | ZSPD0050 | ZSPD0060 | |||
| Solar PV modules | 18V/30W*1PC | 18V/50W*1PC | 18V/60W*1PC | |||
| Battery capacity | 12Ah/12.8Vdc，LFP(LFP)*1PC | 18Ah/12.8Vdc, LFP(LFP)*1PC | 20Ah/12.8Vdc，LFP(LFP)*1PC | |||
| Accessories details | 8m PV cable*1PC，3W/310lm LED light*3PC，5m light cable*3PC，five in one USB cable | |||||
| Output port | 5Vdc/1A USB port*2，12.8Vdc/2.5A output port*6(LFP). | |||||
| LED lights | Solar charging indicator, battery power indicator, load status indicator | |||||
| Protection function |
Overcharge protection, overdischarge protection, overcurrent protection, short circuit protection, PV polarity reverse connection
protection |
|||||
| Size(L*W*H (mm)) | 220*170*163 | |||||
| Total weight（kg） | 2.8 | 3.5 | 5 | |||
| Working hours | 17hrs for 3 LED lights（3W） | 25hrs for 3 LED light（3W） | 28hrs for 3 LED lights（3W） | |||
