Supporting battery type: Lead acid,Gel Battery,Ternary lithium battery,Lithium iron phosphate battery
Hybrid Controller Features:
1.Wind turbine generator breeze charging, MPPT boost intelligent regulation.
2.Wind turbine generator PWM stepless unloading, external unloader, solar intelligent disconnection charging.
3.Dual power supply function of the controller: Battery + solar power supply.
4.LCD displays the voltage and current of battery, fan, solar energy and load, and some parameters can be set.
5.The load output is adjustable in a variety of working modes.
6.High performance and stable chip control.
7.The internal circuit board of the controller is sprayed with three anti paint, which can prevent dust, moisture and static electricity.
A variety of protection, let you rest assured to use:
Protection function | Function description |
Solar anti reverse charging | In the case of poor light at night, the voltage of the battery may be higher than the terminal voltage of the solar cell array. The controller is equipped with an anti reverse charging circuit to prevent the battery from reverse charging the solar cell. |
Battery reverse connection protection | When the battery is connected reversely, the controller does not work and there is no display. The internal fuse protects the controller circuit. If it cannot work normally after the positive and negative poles of the battery are correctly connected, replace the fuse. |
Battery open circuit protection | After long-term use, the battery may have an open circuit or poor contact. The controller will protect the equipment from damage after the battery is open. Please check the line connection regularly. |
Over-voltage and over-current Load overload protection | Under the over-voltage state of the wind turbine generator, the controller will automatically start the braking function to protect the wind turbine and battery. In case of overload, the controller will automatically cut off the circuit。 |
Lightning protection | Lightning protection refers to the last level of protection necessary for equipment. For lightning prone areas, a multi-level lightning protection system composed of special lightning arresters is required. If the user has such requirements, it is necessary to increase the corresponding distribution system and cost, which shall be explained when ordering. |
2800W Controller parameter
Rated system voltage | 12/24 AUTO | |||||||
Model | 700W | 1200W | 1400W | 20000W | ||||
Battery | 12V | 24V | 12V | 24V | 12V | 24V | 12V | 24V |
Rated wind power | 200 | 400 | 300 | 600 | 400 | 800 | 500 | 1000 |
Rated PV power | 150 | 300 | 300 | 600 | 300 | 600 | 500 | 1000 |
Max input voltage | Wind turbine≤80Vsolar panel≤55V | |||||||
Rate system Voltage | 24V48V auto Match | |||||||
Model | 1200W | 2000W | 2200W | 2800W | ||||
Battery voltage | 24V | 48V | 24V | 48V | 24V | 48V | 24V | 48V |
Rated wind power | 300 | 600 | 500 | 1000 | 600 | 1200 | 800 | 1600 |
Rated PV power | 300 | 600 | 500 | 1000 | 500 | 1000 | 600 | 1200 |
Max input voltage | Wind turbine≤80Vsolar panel≤95V | |||||||
No-load Current (DC) | ≤0.05A | |||||||
Controller power mode | Battery or solar | |||||||
Control mode | Wind generator MPPT boost charge、PWM dump load、PWM Over currentLimiting function | |||||||
Outputworking mode(Mode) | Mode 1: Light-control on. Light-control off (3modes adjustable) | |||||||
Display content | LCD display,Voltage,Percentage of battery power, Current, working mode of load,etc | |||||||
Protection type | Solar Reversed Charging protection，Battery open circuit protection、battery anti-reverse connection protection protection、Over current and over voltage auto brake protection、Over load protection,etc. | |||||||
Cooling mode | aluminium profiles Heat dissipation and self-cooling | |||||||
Working temperature / Relative humidity | -25℃~+80℃ /0~90%，non-condensing | |||||||
Net weight / Gross weight | 2.35/2.85kg | |||||||
Controller size/Pack size | 167mm*145.5mm*61.8mm/360mm*250mm*120mm | |||||||
Kindly remind for all buyer:If you use 24v system, your solar panel voltage is not more than 55V. If your system is 48V, please make sure is less 95V, if too high solar panel voltage, controller's MOS tue will be damaged.
Battery parameter reference table：
2. Battery Parameter | |||||||
System Voltage | 12V | 24V | 48V | ||||
(b0)Customer Type | |||||||
FULL | Over Charge | 14.7V | Adjustable | 29.4V | Adjustable | 58.8V | Adjustable |
LOW | Over Discharge | 10.2V | Adjustable | 20.4V | Adjustable | 40.8V | Adjustable |
RLOW | Over Discharge Return | 11.5V | Adjustable | 23.0V | Adjustable | 46.0V | Adjustable |
Special Note: No one-key restore function, please do not modify preset parameters. | |||||||
(b1)Lead acid battery | |||||||
FULL | Over Charge | 14.4V | Default | 28.8V | Default | 57.6V | Default |
LOW | Over Discharge | 10.2V | Default | 20.4V | Default | 40.8V | Default |
RLOW | Over Discharge Return | 11.5V | Default | 23.0V | Default | 46.0V | Default |
(b2)Ternary lithium battery | |||||||
FULL | Over Charge | 12.6V | Default | 25.2V | Default | 50.4V | Default |
LOW | Over Discharge | 9.0V | Default | 18.0V | Default | 36.0V | Default |
RLOW | Over Discharge Return | 11.0V | Default | 22.0V | Default | 44.0V | Default |
(b3)Lithium Iron Phosphate LiFePO4 | |||||||
FULL | Over Charge | 14.4V | Default | 28.8V | Default | 57.6V | Default |
LOW | Over Discharge | 10.0V | Default | 20.0V | Default | 40.0V | Default |
RLOW | Over Discharge Return | 11.0V | Default | 22.0V | Default | 44.0V | Default |
We also provide 2KW off inverter, if you need it, please click on following picture
