The controller will automatically detect the battery voltage 12 volt, 24 volt, or 48 volt, and call the corresponding parameters to charge the battery.
In order to protect the system including the wind generator and the battery, the controller willbrake the wind generator when the battery is completely charged or the input voltage is too high. When the input voltage from wind generator becomes lower, the controller will automatically recover the charging.
Two LED indicators are used toshow the status of the system.
Waterproof body, protection gradeup to IP67.
Wide range working temperature, -35℃～70℃.
Model | HY-800 |
DC rated voltage | 12V/24V/48V |
Battery over-charge voltage | 15V/30V/60V |
Rated Power | 800W |
Temperature-compensation | 8mV/℃/2V-20～65℃ |
Working environment temperature | －20～＋55℃ 35～95%RH |
Storage environment temperature | －30～＋65℃ |
Altitude | ≤5500 M |
Protection | Battery anti reverse,Over-charge protection,Lightning,Current-limit,,Over-temperature,automatic and manual brake. |
N.G | 0.5kg |
Size | 181*77*46mm |
In order to serve our customers better. Our company can adjust parametersconfiguration according to customer’s requirement. | |
