Product Introduction
1)This product does not include the wind turbine tower pole;
2)Free WT060 controller workable for all type batteries;
3)It is necessary to install 3P air switch and SPD between wind and controller, and it is necessary to install an air switch between the controller and the battery;
4)In order to better prolong battery life, please install a battery equalizer between 24V batteries.
5)This is an economical and classic design product. In order to obtain a more stable charging effect, please design and install a wind-solar hybrid power generation system.
1.Unique charging indicator design, whether the output current is clear at a glance;
2.Low speed starting up2 meter/s which improves power efficiency; high wind energy utilization; beautiful appearance; low vibration;
3.High-toughness FRP blades 63CM length with the unique delta wing flow linear blade design is more conducive to capturing wind and wind direction, the blades have such advantages: high utilization of wind energy which contributes to the annual energy output;
4.High-precision NSK bearings, unique generator automatic spot welding technology of magnetic steel and pure copper winding, magnets made of high-purity rare earths ensure high-efficiency and long-life generator quality;
5.Spend a price can Flexible choice to install a 3-blade or 5-blade wind turbine, At the same time, the hub and hood required for the 3 and 5 blades are presented.
Power | Rated power | 400W | 400W | 400W |
Maximum power | 410W | 410W | 410W | |
Rated voltage | 12/24V | 12/24V | 12/24V | |
SKU | 3S3-400 | 5S3-400 | 6S3-400 | |
Blades | Blades Length | 58cm/22.8inch | ||
Wheel Diameter | 130cm/51.2inch | |||
Blades material | High-strength nano-fiber glass fiber | |||
Optional colors | White(default)/Black/Blue/Red/Green/Orange/Yellow/mixed colors | |||
Shape | Ordinary | |||
Blades QTY | 3 PCS | 5 PCS | 6 PCS | |
Wind | Start-up | 2.5m/s | 2.2m/s | 2m/s |
5.6mph | 4.9mph | 4.5mph | ||
Rated speed | 15m/s | 13m/s | 12m/s | |
34mph | 29mph | 27mph | ||
Survival speed | 50m/s | 48m/s | 45m/s | |
111mph | 107mph | 100mph | ||
Generator | Type | 3 phase permanent magnet synchronous(NdFeB) AC generator | ||
Case | Die-casting aluminum | |||
Control system | Electromagnet | |||
Speed regulation | Automatically adjust windward direction | |||
Operation | -40°C- + 80°C | |||
Connector | Hoop(default), Flange to connect with tower pole | |||
Design life | 15 Years | |||
Suggest | Cables | Copper 3 core wind AC cable, waterproof and UV resistant | ||
Tower Pole | 6 meter hight with Steel cable | |||
Others | Approved | CE, ROHS, FCC, ISO, BIWEI | ||
Wind Turbine Generator Controller
Maximum Current:50A
Service for: Sealed( Lead-Acid), GEL battery
Voltage:AC-DC
Battery voltage:12V/24V DC(Auto identify)
Suitable for:0-600W wind turbine
Brakes start voltage:15V(12V Battery); 30V(24V battery)
Waterproof:IP67
Approved:CE,ROHS, FCC, ISO9001
