Specifications:
-Name: Pure sine wave power inverter
-Input voltage: DC 12V for car (9.8~15V)
-Output voltage : AC 220V (210~230V)
-Output frequency: 50Hz
-Peaks Power : 6000W / 4000W / 3000W
-Rated power: 1000W / 800W / 500W (Please make sure that the total rated power of the connected devices is ≤ 1000W / 800W / 500W )
-Product size: 28.6 X10.3X6cm ; 24.5X10.3X6cm ; 21X10.3X6cm
-Maximum Active Surge Rating (less than 1 second) : 6000W / 4000W / 3000W
-Maximum AC Current per socket :8.33Ampere
-Output Waveform: True/pure sine wave (<3% THD)
Efficiency: 90≥%
-No Load Current Draw (DC side) <0.6 A
-8 Safety Protection Function:
Reverse polarity protection, Low input voltage protection, High input voltage protection, Over-current protection, Short circuit protection, Over temperature protection, Overload protection, Internal fuses
Features:
6000W : [Pure Sine Wave] Converts 12V DC to AC 220V household wall power with continuous 1000Watts output ( 6000Watts surge capability) with 1 AC receptacles, one LED Voltage display, high current DC terminals and two LED work lights. (Please make sure that the total rated power of the connected devices is ≤ 1000W).
4000W : [Pure Sine Wave] Converts 12V DC to AC 220V household wall power with continuous 800Watts output ( 4000Watts surge capability) with 1 AC receptacles, one LED Voltage display, high current DC terminals and two LED work lights. (Please make sure that the total rated power of the connected devices is ≤ 800W).
3000W : [Pure Sine Wave] Converts 12V DC to AC 220V household wall power with continuous 500Watts output ( 3000Watts surge capability) with 1 AC receptacles, one LED Voltage display, high current DC terminals and two LED work lights. (Please make sure that the total rated power of the connected devices is ≤ 500W).
[Strong and Durable] Aluminum alloy housing provides advanced protection from drops and bumps.
[LED Green&Red Work Lights] When inverter work normal, the two green LED Lights work, but when it is on protection status, the Red Led Lights will light up.
[LED Voltage Screen display] LED Display shows the battery Input real-time voltage and remind you to charge your battery according to the low voltage.
[Widely Applications ] Great for gift,charging TV, washing machine, air conditioner, refrigerant, Microwave and big power appliance. These can only operate a few 220V loads without interference. It can also use with in the car or solar system.
[Car Becomes RV] With our car power inverter, you can use most of home appliances in your car in the open air, such a watching TV, playing games, give you the experience like being in an RV.
[Silent Intelligent Cooling Fan] Equipped with silent cooling fan, it will automatically runs at different speed according to power load (watt) load and temperature for dissipating heat and reducing working noise. There is a temperature sensor built in the inverter. When it is over 45℃, the fans will work automatically. When the temperature is over 75 ℃-80 ℃, the inverter will be in protection mode till it cool down.
Battery Usage Time Calculation:
1)The working time of inverter, it is depend on the battery power and load power.
2)Formula: Working time (hours)= Battery Capacity X Battery Voltage X 0.8X0.9/Load Power
3) For example, the battery of 12V 60A is supplied to a 220V 100W bulb.
The working time is = 12(V) X 60(AH) X 0.8 X 0.9/100(W)=5.18(hours)
(Note: 0.8 is battery discharge coefficient, 0.9 is inverter conversion efficiency)
What Size Power Inverter Do I Need?
The size you choose depends on the watts (or amps) of what you want to run (find the power consumption by referring to the specification plate on the appliance or tool). We recommend you buy a larger model than you think you'll need (at least 10% to 20% more than your largest load).
2. 20W 18V Solar Panel
Features:
* USB voltage regulator: USB 5V, maximum 3A output, can charge mobile phones, mobile power, GPS, lights and other electronic devices. The problem of outdoor power shortage.
* Cigarette lighter: car battery charger, car battery is insufficient and unable to start the problem.
* Alligator clip: the cost of the 12V battery, to supplement the extra electricity
* Suitable for outdoor, camping, hiking, climbing, traveling, fishing, desert island survival
* Waterproof design, IP65 grade, light and portable, easy to carry.
Specification:
Name: 20W Monocrystalline Solar Panel
Maximum power: 20W
Maximum power voltage: 18V
Maximum power current: 1.12A
Open circuit voltage: 20V
Short circuit current: 1.5A
Number of cells: 36Pcs
Size (W * H):420*280*2.5mm
3.30A Solar Controller
System connection:
1. Connect the battery to the charge regulator-plus and minus.
2. Connect the photovoltaic module to the regulator-plus and minus.
3. Connect the consumer to the charge regulator-plus and minus.
Features:
1. When using the solar controller to charge the battery, the controller will automatically check the voltage.
2. When transferring positive and negative charges to the controller, do not reverse.
3. Connect the solar panel to the solar controller.
Note: Strictly comply with solar panels and solar controllers. Otherwise, the solar controller may be damaged.
Specification:
Name: Solar Controller
Material: PVC
Voltage: 12V/24V automatic identification
Rated charging current: 30A
Rated discharge current: 10A
The highest photovoltaic voltage: 12V system＜23V/24V system＜46V
USB output: 2 USB outputs, maximum 5V/2A
Standby current: <10mA
Working temperature: -35℃~+60℃
Certification: CE RoHS
Size: 133 * 70 * 35mm
Package Included:
1 x Pure Sine Wave Power Inverter 12V-220V
2 x Battery Clip
2 x Alligator Clip
2 x DC Cable
1 x Car Charger
1 x Solar Panel 18W 18V
1 x Solar Charge Controller 30A 12V/24V
1 x User Manual
Note:
1. Please allow 1-3cm (0.4-1.18") difference due to manual measurement and slight color variation for different display setting.
2. Due to the light and screen difference, the item's color may be slightly different from the pictures. Please understand.
