A 5 kW translate 96-110 V MPPT
Product Description 【Inverter Characteristic】: 1,Output wave shape:Pure Sine Wave 2,Can drive inductive load, such as Fridge, TV, Air-condition, Washing machine and Motor etc.
3,Entirely control by CPU, not only increase stability of product quality but also reduce product costing 4,Ultra wide input AC,
range is DC 90V-280V, lever 4 steady pressure 5,Can input different direct voltage, like 12V, 24V, 36V, 48V, 72V, 96V, 110V, 220V,
240V,360V 6,Use RS232 communication port software or SNMP card to realize Remote Data Collect and surveillance 7,LCD liquid
crystal or LED display 8,Output exchange voltage range is 110V 220V 230V 240V 9,Built-in charger,charge by CPU control. Charging
current range 10A-100A(500W-80KW) 10,Output current short-circuit protection, overload protection, high-voltage protection,
low-volatge protection, high-temperature 11,Humanized design. Equipment will automatic start when electric supply. When over-load
it will automatic shutdown and if cancel 【Power Inverter Application System type】: 1,Independent home using electrical power generating system 2,Communication base station system,expressway intelligent monitor
system 3,Outdoor advertisement,The government demonstration project,Landscape lighting engineering 4,Island fishing boat,Remote
mountainous area,frontier sentry etc photovoltaic system
Specification
| Power(W) | 5KW | ||
| Electric Supply input range | 145VAC-280VAC | ||
| Direct current input | 35A-45A | ||
| DC INPUT | 48V/96V | ||
| Input Frequency range | 50/60hz | ||
| Stable pressure output | 220V± 5% | ||
| Inverter output voltage | 110V/220V | ||
| Inverter output frequency | 60HZ/50HZ±1% | ||
| Output sine wave | Pure sine wave | ||
| distortion factor | ≤3% | ||
| Transform time | Within 4ms automatic change | ||
| Inverter efficiency | 0.85 | ||
| Overload ability | 120% 10min 150% 1min | ||
| Cooling model | forced cooling | ||
| Using altitude | ≤1000M(elevation | ||
| Height above 1000M can drop to use) | |||
| Relative humidity | 30%-90% | ||
| Running temperature | 0--40℃ | ||
| Product dimension | (Length*Width*High)48x21x38cm | ||
| Export dimension | (Length*Width*High)56x29x46cm | ||
| Net Weight(kg) | 43 | ||
| Gross Weight(kg) | 45 | ||
| Noise(dB) | 40-60 | ||
| Protection Function |
short-circuit protection, overload protection, high-voltage protection, low-volatge protection, high-temperature protection,
reversed polarity protection and Reverse connect protection etc. |
||
