PWM Charge Controller LCD Display Solar Charge Controller for Home Power Generation for RV
Feature: Specification: Item Type: Solar Charge Controller
2. Multiple Load Working Modes: Adopt temperature compensation, charging parameters can be adjusted automatically. Multiple load working modes, convenient for the product to be applied to different types of loads.
3. Multiple Protection: Our controller can connect two solar panels, which is more efficient than other controllers. Provide overcharge, overdischarge, overload protection and short circuit protection.
4. Convenient and Quick: With advanced load starting method, large capacity loads can be started smoothly. Provide one key human machine interface. Humanized browser and dynamic interface design ensure convenience and speed.
5. TVS Anti Light Protection: Operation is intuitive. With industrial grade design, the product can work normally under various harsh conditions. Adopt TVS anti light protection.
6. Power Failure Memory Function: The solar controller is equipped with LCD display, which can clearly show the status and data, easily switch the mode and parameter configuration, large LCD display with backlight, adjusting recharging and discharging parameters, with power failure memory function.
Material: ABS
Size: Approx. 161x60mm/6.34x2.36in
Charging Type: PWM
Operating Voltage: 12V or 24V Auto Identification
Maximum Charging and Discharging Current: 40A
Maximum PV Input Power: 520W (12V), 1040W (24V)
USB Output Voltage: 5V/2A
Standby Consumption: ≤12mA
Operating Temperature: -20℃ - +55℃
Terminal Wire Gauge: 28 - 10AWG
Waterproof Grade: IP32
Applicable Scenario: Home power generation, base station, RV, yacht, ship and other solar PV systems.
Package List:
1 x Solar Charge Controller1 x User Manual
