Technician Specification | |
Length | 1165mm | Weight | 7.5 kg |
Width | 552mm | Main material* | Mono crystalline |
Height | 30 mm | Frame material | Aluminum |
Electrical Specification
Performance Under Standard Test Conditions(STC*) | |
Maximum power | Pmax | 100 Wp |
Open circuit voltage | Voc | 21.12 V |
Maximum power point voltage | Vmpp | 18.02 V |
Short-circuit current | I sc | 5.98 A |
Maximum power point current | I mpp | 5.55 A |
Minor reduction in efficiency under partial load conditions at 25degC: at 100 W/m2, 95%- (+/-3%) of the STC efficiency (1000 W/m2) is achieved.
Component Material | |
Cells per module | 36 | Cell dimensions | 125mm*125mm |
Cell type | Monocrystalline Silicon | Front | tempered glass (EN12150) |
System Intergration Technician | |
Maximum system voltage SC II | 1000 V | Maximum reverse current | 16 A |
Maximum system voltage USA NEC | 600 V | Increased snowload acc. to IEC 61215 | 5.4 kN/msup2; |
Thermak Characteristics | |
NOCT | 47 degC | TC Voc | -0.33 %/degC |
TC Isc | 0.042 %/degC | TC Pmpp | -0.45 %/degC |
Extra Specification | |
PTC rating | 100 W | Module efficiency | 17.0% |
Junction box | IP65 | Plus-Sorting* | Pflash ge Pmax |
Connector | MC4 | Power tolerance* | +/- 3 % |
Products Display
Quality & Warranty
1. Rigorous quality control meets the highest international standard
2. 5 years limited warranty on material and workmanship
3. 25-year performance guarantee at 80% of the minimal rated power output
4. 10-year performance guarantee at 90% of the minimal rated power output
