Product Introduction
Intelligent Wind Solar Hybrid Controller is special designed for hybrid wind solar power system charge for low-power street lamp, monitoring etc. . And it is workable for GEL, Lead-acid battery with full charge and discharge protection. Large size LCD screen is convenient for parameter(from solar, wind and battery) query but low power self-consumption. It can be flexibly installed in cruise ships, RVs, and land indoors. Powerful functions and light size but very good heat dissipation are its outstanding features.
12/24V auto match for 0-800W wind, 0-600W solar system. Wind turbine charging adopted booster MPPT technology, which makes under low wind speed, the Wind turbine's electricity can still be used.
In the high wind speed or the Wind turbine of power is beyond the scope of the battery and load absorption, the controller immediately launched the stepless unloading function,protection system of the equipment.
Discharge part working mode can be set, light control mode, time control function etc, The user can be set up according to the requirements on its own combination.
Manmachine interface of the controller USES a custom LCD screen and four key operation mode, the user to use simple and easy to use, popular and easy to understand, convenient and quick.
The controllers with perfect protection function, including: lightning counter-attack, solar charger, over-voltage automatic braking, storage battery reverse connect and open protection, etc.
System Parameter | ||||||||
Model | 450W30 | 500W30 | 750W50 | 900W60 | 1100W60 | 1200W60 | 1400W80 | |
System Rated Voltage | 12V(9V-16VDC) | 24V(18V-32VDC) | ||||||
Solar Module | Voc | 27.6V | 55.2V | |||||
Vmp | >Vbat+1V | >Vbat+1V | ||||||
Imp | 8.3A | 11.1A | 13.9A | 16.7A | 16.7A | 20A | 20A | |
Workable Power | 0W~150W | 0W~200W | 0W~250W | 0W~300W | 0W~500W | 0W~600W | 0W~600W | |
Wind Turbine | Rated Voltage | 12VAC（20.8VDC） | 24VAC(41.6VDC） | |||||
Rated Current | 16.7A | 16.7A | 27.8A | 33.3A | 20A | 20A | 26.7A | |
Workable Power | 0W~300W | 0W~300W | 0W~500W | 0W~600W | 0W~600W | 0W~600W | 0W~800W | |
DC Load | Out Power | 0W~180W (Per one-way) | 0W~700W (Per one-way) | |||||
Rated Voltage | 12VDC | 24VDC | ||||||
Current Max | 30A(15A*2) | 30A(15A*2) | ||||||
Battery | Max Charging | 25A | 27.8A | 41.7A | 50A | 36.7A | 40A | 46.7A |
Special Note: No one-key restore function, please do not modify preset parameters. | ||||||||
Uunder | Over Discharge Voltage | 10.8V | 21.6V | |||||
Runder | Over Discharge Return | 13.1V | 26.2V | |||||
Uover | Over Charge Voltage | 15.5V | 31.0V | |||||
Rover | Over Charge Return | 15.0V | 30.0V | |||||
BCV | Increase Charge | 14.4V | 28.8V | |||||
Float | Floating Charge | 13.8V | 27.6V | |||||
Ufanbraking | Wind Breaking Voltage | 25.6V | 51.2V | |||||
No-load Current | ≦0.1A | |||||||
Voltage drop (DC) | ≦0.5V | |||||||
Control mode | Wind turbine MPPT charge function, PWM uninstall function, PWM over-current limiting | |||||||
Boost charge | Flexible independent step-up circuit (optional) | |||||||
Environment | Temperature | 1) Working:-20℃ ～50℃; 2)Storage:-30℃ ～70℃ | ||||||
Humidity (°C) | 10%～90% No condensation | |||||||
Protection Grade | IP30 | |||||||
