About Delivery
Product in stock. Support Drop Shipping and Wholesale Order, Feel Free To Contact Us For Details and Discount.
Support customized, contact us to learn more, design your own panels.
Order1pcs, sent with10A controller
Order2pcs, sent with20A controller
Order3pcs, sent with30A controller
Order4pcsand more, sent with30A controllerandextra accessories pack
(10A Controller+Extension Cord+Parallel Connection+Alligator Clip)
Solar Panel 18V 300W 600W ETFE Solar Power Generator System Solar Panel Kit Complete RV Car Battery Charger For Home Outdoor RV
100W 18V Flexible ETFE Cover Solar Panel, Light Weight, High Performance
High quality monocrystalline solar cell, covered by ETFE layer, high-efficiency outdoor clean power source.
ETFE rugged cover, other than solar cell protection and ensure the flexibility, it can also reflect the sunlight and use the light again and optimized every sunlight.
It can bend to 30 degrees to installed on RVs, boats, houses, tents or any other outdoor scenes. Clean energy and environmentally friendly, suitable for outdoor activities, travel or camping.
White color layer, better heat dissipation when the panel is working.
100% IP67 Waterproof, Easy To Clean, Free Controller and More
IP67 waterproof junction box and M4 connector, stable performance under bad weather or high temperature.
Unlike PET cover, ETFE can easily cleaned by rain or water, simple flush can clean it. (Stain on panel surface might effect the efficiency)
LCD screen controller to monitor the panel's performance, also can control the system status.
Free accessories for 4 pcs and more orders(10A Controller+Extension Cable+Parallel Connector+Alligator Clip)
Parameter
Color: Black+White
Layer Material: ETFE
Size: 1150*540*3mm
Maximum Power (Pmax): 100W
Working Power Voltage (Vmp):18.1±0.3V
Working Power Current (Imp): 5.55A
Shortcut Power Current: 6.11A
Open-Circuit Voltage (Voc): 21V±0.8V
Maximum System Voltage: 1000V
Nominal Operating Cell Temp.(NOCT):-45 to 80℃
Weight: 2.7KG
Packing List
100W Solar Panel*1/2/3/4/5/6
M4 Connector*1/2/3/4/5/6
10/20/30A Controller*1
Packing*1
Notes
1. Please don't scratch the surface of the panel with a sharps object. Do not modify the PCB circuit unless you are professional. We have no responsible for any a result from this.
2. Make sure the solar panel exposed to direct sunlight to ensure the best charging efficiency while charging. Best working time: 9:00-17:00 ( Cloudless Weather ).
3. Product deigned to extend battery life and emergency usage. Please choose other higher current products if you want a faster charging speed.
4. Product deigned with daily water proofing, please don't exposed the charger in rainny day for too long.
5. Keep the front surface clean or it will effect the panel efficiency.
About ETFE Cover
ETFE cover is a new technique in solar panel industry, unlike traditional
PET cover, the surface of ETFE is a bit rugged, which allowsETFE panel has better light-reflection and light-utilization.Not only better conversion rate, it also has better performance in waterproof and dustproof, can survive different bad weather.
Suitable for: Outdoor Activities, House Power Supply, Bad Condition Area, or Need A High Quality Solar Panel.
