Features:
* [LED green and red work light] When the inverter is working normally, the green LED light works and tells you that it is working normally, but when it is in a protection state, such as low voltage, high voltage, over temperature or overload, the red light is on, You need to turn off the inverter, check which protection function is working, and try to solve the problem before the inverter can work again.
* [Intelligent LCD voltage screen display] The color intelligent LCD screen displays the battery input voltage and output voltage in real time. When the battery voltage is lower than 10.5V, the inverter is under low voltage protection. Please try to fully charge the battery and try again. When the battery voltage is higher than 15V, inverter high voltage protection)
* [Multiple protections] Built-in fuse, safe charging design and cooling fan to prevent the car power converter from overheating, energy saving, overvoltage, overload, overcurrent, short circuit, undervoltage, overheating, short circuit protection.
* [Lightweight design & top quality] Lightweight and compact, very suitable for vacation, camping and work trips. It can be plugged into almost any vehicle with 12V power output, providing charging opportunities anywhere.
Specification:
Inverter:
Input voltage: DC 12V
Output voltage: AC 110V, AC 220V
Output frequency: 60Hz,50Hz
Peaks Power: 4000W, 6000W
Rated power :300W, 500W
Output waveform: Modified sine wave
Size: 20.5*11.7*5.8cm (8.1 x 4.6x 2.3 inch)
Color: Blue
Solar panels:
Material: Aluminum substrate + efficient chip + PET
Power: 18W
DC output: 12V / 1.5A
USB output: 5V / 1.7A
Size: 420 * 280 * 2.5mm
Solar Controller:
Voltage: 12V/24V
Rated charging current: 30A
Rated discharge current: 10A
The highest photovoltaic voltage: <41V
Floating charge voltage: 13.7V (adjustable range 12.7-15V)
Discharge cut-off voltage: 10.7V (adjustable range 9-11.3V)
Discharge recovery voltage: 12.6V (adjustable range 11.5-13V)
Standby current: <10mA
USB output: 5V/2A Max
Working temperature: -35~+60℃
Size: 133.5 * 70 * 35mm
Packing included:
1 * Inverter
1 * English inverter manual
2 * Red and black battery clip
1 * Cigarette lighter
1 * Solar controller
1 * English controller manual
1 * Solar panel
1 * DC line
1 * DC alligator clip
Note:
▲.This is a modified sine wave inverter, NOT applicable for devices which work by built-in motor, hair dryers, air conditioners, coffee machine, water pump, induction cooker, refrigerators and microwave ovens etc. Make sure that the total rated power of the connected devices is ≤ 400W
▲.Tighten the Positive (+) and Negative (-) terminals when the car converter is in use
▲.If the converter is directly connected with the cigarette lighter. The highest output power must be under 150W. If higher than 150W, we strongly recommend you using the Crocodile Clips to a battery, because car cigarette lighter might not afford power over 150W.
▲.The car converter suitable for DC12V Car ONLY, not applied for DC 24V car and airplane
▲.Please do not leave the inverter in the ON position before car start. It's easy to damage the inverter before connected to the battery. The correct operation is connect to the battery first and then turn on the inverter switch
▲.It's normal for the inverter to become warm while you are using it. In order to get the best using results, please put the inverter on the flat surface The working place should meet the following criteria:
① Keep dry, should not let the inverter contact the water or other liquids, keep the inverter away from moisture or water.
② Cool environment, keep the temperature between 0 Celsius degrees and 40 Celsius degrees. Do not put the inverter next to heat vents or other devices. Try to keep the inverter not be shined directly by the sunshine.
▲.When the battery voltage is lower than 10.5V, the inverter is low voltage protection, when the battery voltage is higher than 15V, the inverter high voltage protection
