Solar panel generate electricity, 80w black ETFE flexible solar panel charges 12v 24v battery
Product Description1)This product is a multifunctional solar charger, which can charge for big battery,like boat,yacht,car;
2)Semi flexible design,Graceful appearance,delicate and cabinet;
3)Convenience to take , fashionable elegance. MC4 connector can be suitable to connect controller.
4)Especially suitable foranywhere can obtain sunshine,realize high-efficient charging, use convenient and safe, environmental protection, energy saving.It is good for promotion, sales, gifts etc.
5)Waterproof for outside anywhere.
Parameter:
80W ETFE Solar Panel Charger | ||||
Product | semi flexible Solar Panel | Model | ETFE 32-80 | |
Peak-power(W) | 80W | |||
VPM(V) | 18V | |||
Maximum current(A) | 4.44A | |||
Voc(V) | 20V | |||
Isc(A) | 4.65A | |||
Maximum system voltage(V) | 1000V | |||
Cellsconversion(%) | 23.5% | |||
moduleConversion(%) | 23.5% | |||
Cells type | high efficiency solar cell | |||
CellsString number(PCS) | Not limited | |||
Cellsspecification (mm) | 125*125 | |||
peak-power temperature coefficientPm(%/℃) | -0.45%/℃ | |||
Voctemperature coefficient(%/℃) | -0.35%/℃ | |||
tolerance(%) | ±5% | Isc temperature coefficient(%/℃) | +0.05%/℃ | |
Working temperature | -20℃~65℃ | Test standard | Am1.5 25℃1000W/m2 | |
NET Weight | 1.5KG/4.86Ibs/77.95oz | Specification: Extending Size | 86*54*0.3CM | |
Thestructure of Solar cells | ETFE+ EVA +Sunpower solar cell+ EVA+TPT | |||
accessories | Cable with crocodile clips(optional) | |||
Output connector:MC4 | ||||
Lead cable requirements:Resistance to high and low temperature, anti-sunshine exposure | ||||
One complete product includes :
1.100W semi flexible solar panel
2. Special carton package
1)Wonderful details design:
2)Accurated size shown:
Package of portable solar panel :
