The controller will automatically detect the battery voltage 12 volt or 24 volt and call the corresponding parameters to charge the battery.
In order to protect the system including the wind generator and the battery, the controller willbrake the wind generator when the battery is completely charged or the input voltage is too high. When the input voltage from wind generator becomes lower, the controller will automatically recover the charging.
Three LED indicators are used toshow the status of the system.
Waterproof body, protection gradeup to IP67.
With better heat dissipation than others. Wide range working temperature, -35℃～70℃.
Model Number | SF08-12-24-A | |
Rated Powerof the Wind Generator | 100W/200W/300W/400W/500W/600W/700W/800W | |
Rated Voltage of the Battery | 12V | 24V |
Brake Voltage | 15V | 30V |
Recovery Voltage | 13.5V | 27V |
Max Input Current | 30A | |
IndicatorLamps | LED (3 PCS) | |
Dimension | 100mm×87mm×28mm | |
Quiescent Current | ≤15 mA | |
Protection Grade | IP67 | |
Advantage: With Larger size heatsink, good heat dissipation.
Make sure the rated voltage of the wind generator matchwith the rated voltage of the battery.
Don’t directly connect the wind controller with the wind generator until it has been connected with the battery or other DC load.
Connect controller with the battery properly.
The “+” red wire of the controller with the positivepole of the battery, the “-” black wire of with the negative pole of the battery.Connect in order: Connect with the battery first, then connect the three green wires with the AC output of the wind generator.
