Package includes:
1 x Power Inverter
2 x Battery Clip
1 x Cigarette Lighter Plug(gift)
1 x User Manual
1 x Solar Panel 36W 18V+DC cable + DC alligator clip
1 x 30A Solar Charge Controller
Features:
[Car Power inverter] Car power inverter with 2 USB ports and one AC outlet. The power inverter comes with free cigarette lighter and 2pcs battery clips, providing 300Watt continuous power, 4000watt peak power (Please make sure that the total rated power of the connected devices is ≤ 300W). Cigarette lighter cable can supply power for device easily. If the output power is higher than 150W, please using the Crocodile Clips to a battery.
[LED Green & Red Work Lights] When inverter work normal, the green LED Lights work and tell you it is working well, but when it is on protection status, such as low voltage, high voltage, over temperature, or over load, the Red Led Lights will light up and you need to turn off the inverter, and check which protection function is work, and try to solve it then the inverter can work again.
[Intelligent LCD Voltage Screen display] Colorful intelligent LCD Display shows the battery Input battery voltage, output voltage, Battery capacity, frequency 50Hz, load capacity in real-time, which can help you to know the state of inverter conveniently.
[Fast Charging Dual USB ports] One AC Outlets and support two USB charger ports(Max 4.2A) to work at same time and it can offer 100% fast charging for Mobile phones, computers, laptop, breast pump, Nebulizer, Razors, medical rescue device, emergency equipment etc. Easily meet the power supply needs of the diverse vehicle electrical appliance and it can be as an Emergency Power Supply.
[Multi Protection] Built-in fuses, safe charging design and cooling fan prevents the car power converter from over-heat, saving power and energy, over voltage, overload, over-current, short circuiting, under-voltage, overheating, short circuit protection.
[Lightweight design &Top Quality] Lightweight and compact, ideal for vacations, camping and work trips. It can be plugged into almost any 12V power output vehicle, providing charging opportunities anywhere.
Specification:
1. Solar Panel 36W 18V:
Power: 36W± 5%
Size: 840x420x2.5mm
DC output: 12V/1.5A
USB output: 5V/2.1A
Weight: 1.2kg
Type: Mono Solar Panel
Protect rate: IP65
Max powers: 36W
Color: blue & black
Max solar input: ＜50V output: 12/ 24 V auto adapt
Floating charge voltage: 13.6-13.8V
Discharge stop voltage: 14V
Discharge reconnect voltage: 10V
Operating temperature: -20℃ to 60℃
Material: Aluminum substrate + efficient chip + PET
Output accessories: 2 X DC cable + DC alligator clip + DC Cigarette Lighter Cable
2. 30A 12V 24V Solar Charge Controller
Charge Current: 30A
Product Size: 148.5x78x35mm
Voltage: DC 12V / 24V Auto intelligent conversion
Display: LCD digital display
USB Charger Ports: Dual USB 5V 2.1A
Operating Temperature: -35~+60
Max Solar Input: 12V battery, the highest 23V
Float Charge: 13.7V (default, adjustable)
Discharge Stop: 10.7V (defaul, adjustable)
Discharge Reconnect: 12.6V (defaul, adjustable)
Charge Reconnect: 13V
Voltage of Open Light: Solar Panel 8V (Light lights delay)
Voltage of Close Light: Solar Panel 8V (Light off delay)
USB Output: 2 way USB output, 5V/2.5A (MAX)
3. Power Inverter 4000W:
Color: Black
Name: Car power inverter
Input voltage: DC 12V (12V is generally for cars, Voltage Range: 10.5V~15V)
(When the battery voltage is lower than 10.5V, the inverter will in low voltage protection. When the battery voltage is higher than 15V, the inverter will in high voltage protection)
Output voltage: AC 220V (Available Range Of Rated Voltage Of Electrical Appliances: 200~240V)
Output frequency is: 50Hz
Peaks Power: 4000W
Rated power: 300W (Make sure that the total rated power of the connected devices is ≤ 300W)
Output waveform: Modified sine wave
Product Size: 20X11.2X5.6cm
Package Size: 7.87x4.4x 2.2 inch
Weight: 0.65 kg
NOTE: The modified sine wave inverter is suitable for resistive load appliances, such as mobile phones, TV, computers, digital cameras, video cameras, incandescent lamps, rice cookers, electric kettles, non-laser printers, low-power electric tools, etc. (The power of the connected equipment cannot exceed the rated output power of the inverter)
- 8 Safety Protection Function:
①Reverse polarity protection
②Low input voltage protection
③High input voltage protection
④Over-current protection
⑤Short circuit protection
⑥Over temperature protection
⑦Overload protection
⑧Internal fuses
Battery Usage Time Calculation:
1) The working time of inverter, it is depend on the battery power and load power.
2) Formula: Working time (hours)= Battery Capacity X Battery Voltage X 0.8X0.9/Load Power
3) For example, the battery of 12V 60A is supplied to a 220V 100W bulb.
The working time is = 12(V) X 60(AH) X 0.8 X 0.9 / 100(W)=5.18(hours)
(Note: 0.8 is the discharge coefficient of battery, 0.9 is the conversion efficiency of inverter)
What Size Power Inverter Do I Need?
The size you choose depends on the watts (or amps) of what you want to run (find the power consumption by referring to the specification plate on the appliance or tool). We recommend you buy a larger model than you think you'll need (at least 10% to 20% more than your largest load). And if you want to run several appliance at the same time, you should refer to the total Watt. If you want to run a inductive load for a long time, it`s suggested to buy a pure sine wave inverter.
CAUTION!
-1.This is a modified sine wave inverter, NOT applicable for devices which work by built-in motor, hair dryers, air conditioners, coffee machine, water pump, induction cooker, refrigerators and microwave ovens etc. Make sure that the total rated power of the connected devices is ≤ 300W.
-2.Tighten the Positive (+) and Negative (-) terminals when the car converter is in use
-3.If the converter is directly connected with the cigarette lighter. The highest output power must be under 150W. If higher than 150W, we strongly recommend you using the Crocodile Clips to a battery, because car cigarette lighter might not afford power over 150W.
-4.The car converter suitable for DC12V and Car ONLY, not applied for DC 24V and airplane
-5.Please do not leave the inverter in the ON position before car start. It's easy to damage the inverter before connected to the battery. The correct operation is connect to the battery first and then turn on the inverter switch
-6. It's normal for the inverter to become warm while you are using it. In order to get the best using results, please put the inverter on the flat surface The working place should meet the following criteria:
1. Keep dry, should not let the inverter contact the water or other liquids, keep the inverter away from moisture or water.
2. Cool environment, keep the temperature between 0 Celsius degrees and 40 Celsius degrees. Do not put the inverter next to heat vents or other devices. Try to keep the inverter not be shined directly by the sunshine.
