Features:
1. High Temperature Warning Indicator in LCD display: When high temperature over 60 Celsius, the symbol of temperature will light up and show red color, plus audible alarm then shutdown.
2. Show Battery Power in LCD display: Green means full power, yellow means half level, and red means low power of your battery, you have to recharge the battery at once.
3. High Voltage warning in LCD display: (1) When high voltage warning, the symbol of v lights up(Red), battery level bar flickers, input voltage display shows 15V or more, plus audible alarm then shutdown. (2) When low voltage warning, the symbol of v lights up(Red), battery level bar flickers, input voltage display shows 10.5V or less, plus audible alarm then shutdown.
4. Power on/off indicator in LCD display: The symbol show green means working normal, show red and faulty means without output.
5. Over load & Short circuit in LCD display: When overload, the symbol (like a balance scale) will light up(Red), load level bar flickers, no outputs audible alarm. When Short circuit warning, the symbol (like a balance scale) will light up(Red), load level bar flickers, no outputs audible alarm.
6. MCU LCD Display: Car inverter has the micro-control unit LCD realizes the exchange of human-machine information, and can know the working status of the inverter in real time, including show real time of input voltage, output voltage, output frequency, battery power, load, Power on/off indicator and other information.
7. Fast Charging Dual USB ports: One AC Outlets and two USB ports can offer 100% fast charging for Mobile phones, computers, laptop, breast pump, Nebulizer, Razors, fan, camera, DVD players, lights, medical rescue device, emergency equipment etc, can be as a Emergency Power Supply. AC outlets great for laptop, drone, fan, camera, CPAP machine, game console, kindle, TV, DVD players, lights, iPad, RV, and other electronic devices.
8. Multi Protection: Built-in fuses, safe charging design and cooling fan prevents the car power converter from over-heat, saving power and energy. over voltage, overload, over-current, short circuiting, under-voltage, overheating, short circuit protection.
9. Lightweight design &Top Quality: Lightweight and compact, ideal for vacations, camping and work trips. It can be plugged into almost any 12V power output vehicle, providing charging opportunities anywhere.
Specification:
1. Solar Panel 18W:
Power: 18W± 5%
Size: 420x280x2.5mm
DC output: 12V/1.5A
USB output: 5V/1.7A
Type: Mono Solar Panel
Material: Aluminum substrate
Output accessories: DC cable + DC alligator clip
2. Power Inverter 6000W:
Input voltage: DC 10.5V~15V,
(When the battery voltage is lower than 10.5V, the inverter is low voltage protection, when the battery voltage is higher than 15V, the inverter high voltage protection)
Output voltage: AC 220V
Output frequency is: 50Hz
Peaks Power: 6000W
Rated power: 500W (Please make sure that the total rated power of the connected devices is ≤ 500W).
Output waveform: Modified sine wave
Product Size for inverter: 200x112x56mm
NOTE: The modified sine wave inverter is suitable for resistive load appliances, such as mobile phones, TV, computers, digital cameras, video cameras, incandescent lamps, rice cookers, electric kettles, non-laser printers, low-power electric tools, etc. (The power of the connected equipment cannot exceed the rated output power of the inverter)
3. 30A 12V 24V Automatic Solar Charge Controller PWM with LCD Controller and Dual USB
Charge Current: 30A
Product Size: 148.5x78x35mm
Voltage: DC 12V / 24V Auto intelligent conversion
Display: LCD digital display
USB Charger Ports: Dual USB 5V 2.1A
Operating Temperature: -35~+60
Max Solar Input: 12V battery, the highest 23V
Float Charge: 13.7V (default, adjustable)
Discharge Stop: 10.7V (default, adjustable)
Discharge Reconnect: 12.6V (default, adjustable)
Charge Reconnect: 13V
Voltage of Open Light: Solar Panel 8V (Light lights delay)
Voltage of Close Light: Solar Panel 8V (Light off delay)
USB Output: 2 way USB output, 5V/2.5A (MAX)
Battery Usage Time Calculation:
1)The working time of inverter, it is depend on the battery power and load power.
2)Formula: Working time (hours)= Battery Capacity X Battery Voltage X 0.8X0.9/Load Power
3) For example, the battery of 12V 60A is supplied to a 220V 100W bulb.
The working time is = 12(V) X 60(AH) X 0.8 X 0.9/100(W)=5.18(hours)
(Note: 0.8 is battery discharge coefficient, 0.9 is inverter conversion efficiency)
What Size Power Inverter Do I Need?
The size you choose depends on the watts (or amps) of what you want to run (find the power consumption by referring to the specification plate on the appliance or tool). We recommend you buy a larger model than you think you'll need (at least 10% to 20% more than your largest load).
CAUTION
1. Tighten the Positive (+) and Negative (-) terminals when the car converter is in use
2. If the converter is directly connected with the cigarette lighter. The highest out put power must be under 150W. If higher than 150W,we strongly recommend you using the Crocodile Clips to a battery ,because car cigarette lighter might not afford power over 150W.
3. The car converter suitable for DC12V and Car ONLY, not applied for DC 24V and airplane.
4. Please do not leave the inverter in the ON position before car start. It's easy to damage the inverter before connected to the battery. The correct operation is connect to the battery first and then turn on the inverter switch.
5. It's normal for the inverter to become warm while you are using it. Please put the inverter on the flat surface The working place should keep dry, keep the inverter away from moisture or water. Do not put the inverter next to heat vents or other devices(between 0 Celsius degrees and 40 Celsius degrees). Try to keep the inverter not be shined directly by the sunshine.
Packing included:
1 x Power Inverter
2 x Battery Clip
1 x Cigarette Lighter Plug(gift)
1 x 18W 18V Solar Panel + DC cable + DC alligator clip
1 x Solar Charge Controller 30A 12V/24V
1 x User Manual
