Solar Panel Kit Complete 3000W4000W/6000W/8000W Pure Sine Wave Power Inverter Home Solar Power Generation System with 30A Solar Controller
Solar Panel Features :
* USB voltage regulator: USB 5V, maximum 3A output, can charge mobile phones, mobile power, GPS, lights and other electronic devices. The problem of outdoor power shortage.
* Cigarette lighter: car battery charger, car battery is insufficient and unable to start the problem.
* Alligator clip: the cost of the 12V battery, to supplement the extra electricity
* Suitable for outdoor, camping, hiking, climbing, traveling, fishing, desert island survival
* Waterproof design, IP65 grade, light and portable, easy to carry.
Specification:
Name: 20W Monocrystalline Solar Panel
Model: JH-20W
Maximum power: 20W
Maximum power voltage: 18V
Maximum power current: 1.12A
Open circuit voltage: 20V
Short circuit current: 1.5A
Number of cells: 36Pcs
Power Inverter 3000W/4000W/6000W/8000W
Specifications:
-Name: Pure sine wave power inverter
-Input voltage: DC 12V for car (9.8~15V)
-Output voltage : AC 220V (210~230V)/110V
-Output frequency: 50Hz/60Hz
-Peaks Power : 3000W/4000W/6000W/8000W
-Rated power: 500W800/1000/1300W (Please make sure that the total rated power of the connected devices is ≤ /500800/1000/1300W)
-Product size: 21X10.3X6cm
-Maximum Active Surge Rating (less than 1 second) :4000W/6000W/8000W
-Maximum AC Current per socket :8.33Ampere
-Output Waveform: True/pure sine wave (<3% THD)
Efficiency: 90≥%
-No Load Current Draw (DC side) <0.6 A
-8 Safety Protection Function:
Reverse polarity protection, Low input voltage protection, High input voltage protection, Over-current protection, Short circuit protection, Over temperature protection, Overload protection, Internal fuses
Features:
[Pure Sine Wave] Converts 12V DC to AC 220V household wall power with continuous 1000Watts output ( 6000Watts surge capability) with 1 AC receptacles, one LED Voltage display, high current DC terminals and two LED work lights. (Please make sure that the total rated power of the connected devices is ≤ 1000W).
What Size Power Inverter Do I Need?
The size you choose depends on the watts (or amps) of what you want to run (find the power consumption by referring to the specification plate on the appliance or tool). We recommend you buy a larger model than you think you'll need (at least 10% to 20% more than your largest load).
3. 30A 12V 24V Automatic Solar Charge Controller PWM with LCD Controller and Dual USB
Charge Current: 30A
Product Size: 148.5x78x35mm
Voltage: DC 12V / 24V Auto intelligent conversion
Display: LCD digital display
USB Charger Ports: Dual USB 5V 2.1A
Operating Temperature: -35~+60
Max Solar Input: 12V battery, the highest 23V
Float Charge: 13.7V (default, adjustable)
Discharge Stop: 10.7V (default, adjustable)
Discharge Reconnect: 12.6V (default, adjustable)
Charge Reconnect: 13V
Voltage of Open Light: Solar Panel 8V (Light lights delay)
Voltage of Close Light: Solar Panel 8V (Light off delay)
USB Output: 2 way USB output, 5V/2.5A (MAX)
Packing included:
1 x Power Inverter
2 x Battery Clip
1 x Cigarette Lighter Plug(gift)
1 x 20W 18V Solar Panel
1 x Solar Charge Controller 30A 12V/24V
