ind Solar Hybrid System MPPT Charge Controller 400w~1000w Wind 200w~1000w Solar 12V 24V Auto 48V Regulator For Wind Generator
Wind Solar Hybrid System MPPT Charge Controller 400w~1000w Wind 200w~1000w Solar 12V 24V Auto 48V Regulator For Wind Generator
FEATURES:
1. Waterproof. Waterproof, anti-corrossion, insulated protections are specially designed for circuit board. The housing is also waterproof.
2. Optional TTL232 communication. Standard TTL232 communicationmicro-port make it easy to monitor the system on a computer. (RS485, short distance wireless optional), with USB to RS232 cable, it's very convenient to exchange data between controller and computer.
3. No damage would happen while solar power input is reverse-connected sustainedly. Controller willgo on working after correcting the reversed connection.
4. Boost MPPT input technolog.The controller provides automatic wind turbine MPPT(input maximum power tracking) mode, or 5-segment matching curve input configuration mode (RPM vs input current curve, or input voltage vs input current curve), which could maximize the power generation efficience under low wind speed.
For 12V battery, start charging voltage 6V; For 24V battery, start charging voltage 12V.
5. multiple output modes. The controller provides a variety of output modes(light control, time control, morning light) feasible for various applications.
6. The controller could calculate cumulative power generated, remaining power, RPM, current, temperature and other data.
The controller displays not only conventional data such as output current/voltage/power of wind turbine/solar panel/battery, but also the cumulative power generated by wind/solar, remained battery power and RPM.
Wind: input voltage/current/power/cumulative power/RPM/unloading current
Solar: input voltage/current/power/cumulative power
Battery:Voltage/charging curent/power/cumulative power
7. Protections:
Wind: Over speed protection,over current protection, induced lightning strike protection
Solar: Reverse connection protection
Battery: Reverse polarity protection(fuse burn-out), over voltage protection, low voltage protection(for street lights)
Insulation Grade: IP41
SPECIFICATIONS:
PACKING LIST:
1.MPPT controller 1 piece.
2.USB extension cord 1 piece.(optional)
3.Degital cable 1 piece.(optional)
REMINDER:
1.The price you paid for the item excludes any customs tax.We will not shoulder any duties in destination country.
2.Please check with your country customs office to determine what these additional costs will be prior to bidding/buying.
3.All informations(products model No.,test result,specification,features,pictures,ect) that we provided are just for reference, Details pls refers to the real prodcut, instruction you received. All datas are our internal lab test results, and it might have a little discrepency upon different surrounding, pls refers to the exact result of the products after installation.
Dear customers:
Your positive comments is the driving force for our continuous improvement. We respect and trust every customer to provide you with qualified products and services. If you are satisfied with our products, please give us a five-star positive feedback. If you have any questions/problems after receiving the product, please contact us by Ali message as soon as possible and we will try to solve it for you positively at once until you are satisfied. While leaving a negative feedback will not solve any problems!
Thank you for your support!
1. The product warranty period is within 1 year after purchase. (Damage caused by dismantling, manual damage, etc. is not covered by the warranty).
2. If the buyer finds that there is indeed a problem with the product within seven days after receiving the product, buyer could applied to seller to return for inspection. If the product is indeed defective, we will replace it with a new one. If there is no suitable substitute And we will refund you. Shipping, handling and insurance fees are non-refundable. If it is found that there is no problem with the product, the product will be returned to the buyer at the buyer's expense.
3.Please contact us to request a return authorization. Your name, auction number, and reason for return should be included in the email.
4. After receiving the goods, pls remove the tape around the box when unpacking, without violent damage, to avoid potential damage to the goods. It is recommended to keep the outer packaging for at least 15 days after receiving the goods. When returning goods, please ensure the integrity of the original packaging and the goods. If there is any reason that affects the secondary sales of the goods, the return and exchange cannot be accepted. All cost of return and tax will be covered by buyer.
5. When receiving the goods, if you find that the outer packaging is damaged, you should immediately contact the local courier to make a complaint and claim, and at the same time take a photo or video as the evidence and inform the seller. If the buyer fails to follow the above operations , then if the goods are damaged or lost due to courier reasons, the buyer shall take the responsibility.
