Factory price 800W 12v 24v 48v Wind Turbine Generator + 800w Wind Controller / 1000w Wind Solar Hybrid Controller for Home use
https://www.youtube.com/watch?v=ilN9604y4fg
High praise from our European customer, he has bought this wind turbine from us for many times.
If you want a real 800W wind turbine, please buy it today without hesitation !
Monster-class wind turbine, the maximum power generation can reach 1200w, very very incredible
Description:
1. Streamlined design,simple structure,running stably,power supply for city lamp,monitoring and home.
2. Small size and flexibility,lively Colors,beautiful curve,low noise and environmental harmony.
3. Anti-Rust,Anti-Corruption Damp-Proof,Water-Proof,Stand-Proof.
4. Brand New in box
5. CE Certificate
6. ISO9001:2000 Quality Certification
7. Large power, low volume, high efficiency
8. Carbon fiber blades, high efficiency of anti-wind ability,move mutely and steadily
9. Blades with the ability of automatically stall protection under strong wind
10. 3 years free warranty
Technical Description:
Reted power: 800w
Max power: 850w
Rated voltage: 12/24/48vDC
Start up wind speed: 2m/s
Rated wind speed: 11m/s
Survival wind speed: 45m/s
Top net weight: 23kg
Wheel diameter: 1.85m
Blades number: 3 or 5
Blades material: Nylon fiber
Generator: 3 phase ac generator
Magnetic steel: NdFeB
Generator case: Die-casting aluminum
Control system: Electromagnet
Speed regulation: Automatically adjust windward
Package included:
1). 1 x Wind turbine
2). 3 x 900mm blades
3). 1 x Wind turbine hub
4). 1 x Screw bolts and nose cone
5). 1 x Wind controller or Wind solar controller if you buy
6). 1 x Flange
7). 1 x User Manuel
Power Curve
above size is for reference only, it may change due to different batches.
800w Wind Controller
Big Size 1000w Wind Solar Controller=800W Wind + 2000W Solar
MPPT Boost Function for wind turbine
PWM Function for solar panel
if your local wind speed is strong and always over 8m/s, this hybrid controller with a bigger inside dump load is a better match !
Simple Installation:
1. Prepare all mounting parts of the wind turbines ready.
2. Connecting the three AC conductors of the wind turbine to the transmission cable, the length of each pair of conductors is not less than 30 mm, and the tape is tightly tied at 100 mm.
3. Aligning the divided of the wind turbine with the flange holes on the tower, and set up the flat washer and the elastic washer, tighten the nut.
4. Connect the cables of the wind turbines to the controller, and the battery must be connected to the controller before the wiring. Completed.
