Product Description
A: Please kindly be noted the AC output can only charge/power your devices that less than 500 Watts, please check out the operating power of your device before use.
Q: How long it can power to my exact device?
A: Working time = 500Wh* 0.85 / operating power of your device
For your information, if the power consumption of your device was 50W, The running time will be 500Wh*0.85/50W=8.5 hrs (rough calculated).
Battery Level Indicator :
1.The battery level is provided by percentage of battery charge corresponding to the number of bars and percentage displayed.
2.The segments in the battery level correspond to the current state of charge, 0-5% empty, 6- 20% one segment, 21-40% two segments, 41-60% three segments, 61-80% four segments, and all five are lit when charge level is above 81%. 3.Provides the user live telemetry data on time to completely charge, or deplete the battery based upon the energy entering or leaving the battery.
4.Highly recommend to fully charge MP500 when first use. 5.Higher battery level indicator show, more precise the data will indicate. 6.Please be aware that this value can adjust multiple times as the energy draw changes from the connected devices.
7.This is evident during initial activation of ports with a connected device. 8.Recommended to charge the MP500 when battery indicate less than 20%. 9.Note that when you first plug in a power source, whether it*s a solar panel or a wall charger, the MP500 may take a minute to detect and adjust its charge circuitry before it starts drawing power from the source. INPUT Status : The MP500 is capable of providing input energy in watts. DC Output Status : The display will provide output watts of the DC port. AC Output Status : The display will provide output watts of the AC port. USB output status: The display will provide output watts ofthe USB port. Power-saving mode: 10.When the device enters the input or output state, it will enter the screen-off mode after more than 20 seconds, which does not affect the normal operation of the device. When the output power of the device is less than 5W, the device will go into hibernation after more than 3 hours, and the input can be "awakened" when the input is charged or any button is pressed. When not in use, press the switch button to turn off the output.
Packing&Shipping
Product Size:
ES-MMP330:205*155*165mm ES-MMP500:290*194*200mm ES-MMP1000:290*194*200mm
Certifications
| Product Name | Energy storage power |
| Material | PC+ABS+Silica gel environmental protection material |
| Rated power | 330W/500W/1000W |
| Rated Electricity | 288.6Wh/519.48Wh/999Wh |
| Standard capacity | 3.7V/78000mAh / 3.7V/140400mAh / 3.7V/270000mAh |
| Overload Protection | 360±20W / 550±40W / 1100±80W |
| AC output | 110V±10%/60HZ |
| Output waveform | pure sine wave |
| USB output | QC3.0/18W |
| Type-C output | PD60W |
| DC55*2.1 cigarette lighter total output | 12V/10A/14V/8A/14V/8A |
| Wireless charging | 5W&10W&10W |
| Charging input voltage | 12-24V & 12-26V & 12-26V |
| Working temperature | -10-40℃ |
WHAT YOU NEED TO KNOW
Q: What devices can Eshine portable power station MP500 power?A: Please kindly be noted the AC output can only charge/power your devices that less than 500 Watts, please check out the operating power of your device before use.
Q: How long it can power to my exact device?
A: Working time = 500Wh* 0.85 / operating power of your device
For your information, if the power consumption of your device was 50W, The running time will be 500Wh*0.85/50W=8.5 hrs (rough calculated).
Battery Level Indicator :
1.The battery level is provided by percentage of battery charge corresponding to the number of bars and percentage displayed.2.The segments in the battery level correspond to the current state of charge, 0-5% empty, 6- 20% one segment, 21-40% two segments, 41-60% three segments, 61-80% four segments, and all five are lit when charge level is above 81%. 3.Provides the user live telemetry data on time to completely charge, or deplete the battery based upon the energy entering or leaving the battery.
4.Highly recommend to fully charge MP500 when first use. 5.Higher battery level indicator show, more precise the data will indicate. 6.Please be aware that this value can adjust multiple times as the energy draw changes from the connected devices.
7.This is evident during initial activation of ports with a connected device. 8.Recommended to charge the MP500 when battery indicate less than 20%. 9.Note that when you first plug in a power source, whether it*s a solar panel or a wall charger, the MP500 may take a minute to detect and adjust its charge circuitry before it starts drawing power from the source. INPUT Status : The MP500 is capable of providing input energy in watts. DC Output Status : The display will provide output watts of the DC port. AC Output Status : The display will provide output watts of the AC port. USB output status: The display will provide output watts ofthe USB port. Power-saving mode: 10.When the device enters the input or output state, it will enter the screen-off mode after more than 20 seconds, which does not affect the normal operation of the device. When the output power of the device is less than 5W, the device will go into hibernation after more than 3 hours, and the input can be "awakened" when the input is charged or any button is pressed. When not in use, press the switch button to turn off the output.
Packing&Shipping
Product Size:
ES-MMP330:205*155*165mm ES-MMP500:290*194*200mm ES-MMP1000:290*194*200mm
Certifications
