2000W Solar Power Grid Tie Inverter with Limiter DC 22V-66V or 45V-96V AC110V /220VAuto Sensing LCD Display Second Generation

Introduce

Max Efficiency:>92% MPPT Efficiency:99%

1. Low cost and easy installation
2. Directly connect to three phase wind turbine
3. Much better output waveform compare with similiar GTI
4. Improving the efficiency of the entire solar power system
Overload protection ,Anti-island protection
Short-circuit protection/Reverse polarity protection
5. AC output voltage and current THD<5%,PF>99%

This model grid tie has designed for wind turbines that put out 3 phases AC voltage. It can maintain the rotating speed of the wind turbine and keep the voltage from the wind turbine always at the range of the rated range of the grid tie inverter. It also has a high voltage protection function, when the wind is too big, and the dump load controlling system can’t keep the output voltage from the wind turbine, the controller will disconnect itself from the wind turbine, so it is very safe to be used.

Feature

1. Advanced patented technology, MPPT efficiency is higher.

2. High-quality imported components, more stable quality, lower failure rate. Significantly longer life, more than 10 years.

3. Each inverter need to pass twice testing (20 hours) before leaving factory.

4. Warranty: 2 years of free maintenance and replacement, lifetime technical support.

5. Low cost and easy installation .

6. Free combination.

7. Combination of SGPV does not interact.

8. Improving the efficiency of the entire solar power system.

9. Low power consumption.

Specification

Inverter Display Instruction

The Inverter display can show many information,The main interface of the display and the icons explainations are show above.

Set Menu:Choose the set menu icon on the main screen interface,click the confirm button to enter into the interface show below,In this interface,can set the LCD backlight always on or auto turn off backlight after 3 minutes no action.
The inverter also integrate with internal limiter and external limiter function which can prevent excess power from going to the public grid.Select the internal limiter mode,inverter will work under limiter mode,output power of the inverter will be determined by load power.Select the external limiter mode,inverter need a external limiter module working with it.For more details about the limiter function,pls contact supplier. ( this function only useful with limiter type inverter. )

Power view

In this interface,the display shows real time power,PV input voltage, inside temperature,date and time.

Clock And Date Setting

Set the clock and date in this page,save the setting before exit.

Notes: Save the setting after you reconfigurate the working mode or backlight setting.
Notes: Battery Discharge Current Mode And Battery Discharge Power Mode are not developed yet.

Grid Waveform

This interface will show the real time grid waveform.The grid voltage and frequency also will show in this interface.

Energy Menu

The energy interface will show the power generation curve everyday. Today KWH and Total KWH are also show in this page.

AC Output Current Waveform and PF Test Of 2000W Model

Tested 2000W model at nearly full load,Output current waveform shows good pure sine wave in oscilloscope,PF value also shows in good result,99.8% PF value.
