About Product
This product is suitable for solar grid-connected systems, and also suitable for off-grid charging systems. It can also be flexibly combined with wind turbines to form a wind-solar hybrid power generation system. The DC input voltage or charging voltage you want can be obtained by a combination of series and parallel.
For light, thin and flexible, ETFE semi flexible solar panles are a fantastic way to ensure you are topped up with electricity without having the burden of a rigid panel to get in the way.
The available storage in warhouse is from 30w to 200w per peiece. Easily can be attached to anything by drawstring or sealant. Such as the roof of campervan or boat.
The waterproof junction box and MC4 connectors allow simple and rapid connections to electricity storage batteries, ensuring no amoments sunlight is lost.
Constructed with back contact monocrystalline cells outputs a high level of efficiency when compared to other sub-standard flexible solar panels. Even in a bad weather the cells can work optimize performance.
1.Special connection method lowers the internal resistance and ensures better performance than traditional connection with busbar.
High efficiency, solar energy conversion rate up to 21.9-24%,Continuous power supply even in cloudy days.
Rounding corners to prevent from being scratched.Hardening process surface prevent from scratched.
2.IP67 rated junction box, reliable cables and standard MC4 connectors improve the stability
3.Waterproof for outside anywhere.
4.Upgraded efficiency and unprecedented flexibility.
5.Weakened hot-spot effect, extremely low risk of micro cracks and increased stability by shingle-tech.
6.Semi flexible design, Light weight,easy carrying,easy shipment,easy installation.Graceful appearance,delicate and cabinet;
7.Convenience to take , fashionable elegance.male and female connector can be suitable to connect controller.
8.Wide use applications:Golf car,Yacht, boat,caravan, electric car,travel tourism car, patrol car, roof,camping,roof power generations,tent,portable bag , backpacks , portable generator kits etc.
9.Especially suitable foranywhere can obtain sunshine,realize high-efficient charging, use convenient and safe, environmental protection, energy saving.It is good for promotion, sales, gifts etc.
Model | 30-36MFE-24 | 50-36MFE-24 | 60-36MFE-29 | 100-36MFE-29 | 150-36MFE-40 | |
30W | 50W | 60W | 100W | 150W | ||
Cell Type | Monocrystalline | Monocrystalline | Monocrystalline | Monocrystalline | Monocrystalline | |
Cell efficiency | % | 21.40% | 21.40% | 21.40% | 21.4 | 21.4 |
Max Power Current | Imp | 1.70A | 2.75A | 2.80A | 5.19A | 6.82A |
Max Power Voltage | Vmp | 17.60V | 18.15V | 21.45V | 19.25V | 22V |
Open Circuit Current | Voc | 20.80V | 21.45V | 25.35V | 22.75V | 26V |
Short Circuit Current | Isc | 1.94A | 3.26A | 3.32A | 5.71A | 7.31A |
Max System Voltage | DC | 100V | 100V | 100V | 100V | 100V |
Output Tolerance | ≧+3% | |||||
Cable | 900mm/2.5mm2 | |||||
Connector Type | MC4/MC4 Compatible | |||||
Module Structure | ETFE/EVA/Backsheet | |||||
Junction box rating | IP68 | |||||
Number of Diodes | One | |||||
Number of fixing holes | Optional No hole or 6 drawstring/fixing holes | |||||
Working Temperature | # -20℃~+65℃ |
