Manual changeover switch Features:
1.Reasonable structure, small volume, nice appearance, provided with protective shield, safer and more reliable power supply.
2.Complete protective functions, including short circuit, overload, open phase and loss-of-voltage protection.
3.Reliable remote double-break with EPS fire protection power supply interface DC12-24V.
4.Noiseless, energy saving , simple installation , easy operation, reliable and stable performance.
Manual changeover switch Parameters:
Rated Working Current：10A 16A 20A 25A 32A 40A 50A 63A
Rated Working Voltage:AC400V
Controling Voltage：AC230V
Rated Short Circuit Breaking Capacity：3kA
Rated Short Circuit Making Capacity:3kA
Rated Insulation Voltage:AC500V
Transfer Time:≤3S
Frequency:50/60HZ
ATS Level:CB Class
Standard:IEC60947-1
1.Material We choose PC flame retardant material
Security, safe use
2.Handle novel design
Normal And Ready conversion is 3000 times, 1500 times of
electrical life
3.Inside ECuSn-C
Super silver contact, whole copper movement
