4000W Solar Power Generation System 12V to 220V Inverter Kit 30A Controller Battery USB Charger Complete Controller Home Camp
Features:
* [LED green and red work light] When the inverter is working normally, the green LED light works and tells you that it is working normally, but when it is in a protection state, such as low voltage, high voltage, over temperature or overload, the red light is on, You need to turn off the inverter, check which protection function is working, and try to solve the problem before the inverter can work again.
* [Intelligent LCD voltage screen display] The color intelligent LCD screen displays the battery input voltage and output voltage in real time. When the battery voltage is lower than 10.5V, the inverter is under low voltage protection. Please try to fully charge the battery and try again. When the battery voltage is higher than 15V, inverter high voltage protection)
* [Multiple protections] Built-in fuse, safe charging design and cooling fan to prevent the car power converter from overheating, energy saving, overvoltage, overload, overcurrent, short circuit, undervoltage, overheating, short circuit protection.
* [Lightweight design & top quality] Lightweight and compact, very suitable for vacation, camping and work trips. It can be plugged into almost any vehicle with 12V power output, providing charging opportunities anywhere.
Specification:
Inverter:
Power: 300W
Voltage: 12V to 220V
Display: LCD display
Size: 20.5 * 11.7 * 5.8cm / 8.1 * 4.6 * 2.3inch
Color: Blue
Solar panels:
Material: Aluminum substrate + efficient chip + PET
Power: 18W
DC output: 12V / 1.5A
USB output: 5V / 1.7A
Size: 420 * 280 * 2.5mm
Solar Controller:
Voltage: 12V/24V
Rated charging current: 30A
Rated discharge current: 10A
The highest photovoltaic voltage: <41V
Floating charge voltage: 13.7V (adjustable range 12.7-15V)
Discharge cut-off voltage: 10.7V (adjustable range 9-11.3V)
Discharge recovery voltage: 12.6V (adjustable range 11.5-13V)
Standby current: <10mA
USB output: 5V/2A Max
Working temperature: -35~+60℃
Size: 133.5 * 70 * 35mm
Packing included:
1 * Inverter
1 * English inverter manual
2 * Red and black battery clip
1 * Cigarette lighter
1 * Solar controller
1 * English controller manual
1 * Solar panel
1 * DC line
1 * DC alligator clip
