Description:
This solar panel complete system is very suitable for home, shed, cabin, RVs, and more to provide enough power.
Built-in fuses provide overheating, undervoltage and overvoltage, short circuit, overload and overcharge protection.
Specification:
Power Inverter 3000W:
Input voltage: DC 10.5V~15V,
(When the battery voltage is lower than 10.5V, the inverter low voltage protection, when the battery voltage is higher than 15V, the inverter high voltage protection)
Output voltage: AC 220V/110V for your choice
Output frequency: 220V 50Hz, 110V 60Hz
Max power: 3000W
RatedPower: 300W (please ensure that the total RatedPower of the connected device is ≤300W).
Output waveform: modified sine wave
Solar controller parameters:
Charging current: 30A
Product size: about 148.5x78x35mm/5.82*3.07*1.37 inches
Voltage: DC 12V / 24V automatic intelligent conversion
Display: LCD digital display
USB Charger Port: Dual USB 5V 2.1A
Working temperature: -35~+60
Maximum solar input: 12V battery, up to 23V
Float charge: 13.7V (default, adjustable)
Discharge stop: 10.7V (default, adjustable)
Discharge reconnection: 12.6V (default, adjustable)
Charging reconnect: 13V
USB output: 2 USB outputs, 5V/2.5A (MAX)
Solar panel 18W parameters:
Power: 18W±5%
Size: 420x280x2.5mm/16.53*11.02*0.98 inches
DC output: 12V/1.5A
USB output: 5V/1.7A
Weight: 0.7kg
Type: Monocrystalline Solar Panel
Material: aluminum substrate
Output accessories: DC line + DC alligator clip
Package List:
1 x Power Inverter
2 x battery Clips
1 x Cigarette Lighter Plug
1 x User Manual
1 x Solar Panel 18W 18V+DC Cable + DC Alligator Clip
1 x Solar Charge Controller 30A 12V/24V
Notes:
Due to the lighting effects and shooting angles, the color of the item and that shown in the picture might have a nuance.
Due to manual measurement, there might be a tolerance in the product size.
