1.Performancesummary
Thank you for choosing the JN series Privilege Version Wind and Solar Hybrid solar charging controller. This series of products adopts advanced high-speed processor and MPPT control algorithm to ensure MPPT charging at low wind speed, featuring high response speed, high reliability and high indus- trial standard features.
The controller adopts color screen design, the display information is more comprehensive, the display interface is clearer, the controller supports WIFI module and GPRS module to expand and implement APP cloud monitoring. The controller is suitable for solar off-grid system, automatically controls charging and discharging, and can be applied In communication base stations, household systems, street lighting systems and field monitoring and other fields.
2. Product features
● The display adopts color screen design, the display information is more comprehensive, the display interface is clearer, and the 4-key man-machine interface and operation setting are more convenient;
●The MPPT control algorithm used for fan charging ensures MPPT charging at low wind speed.
●Fan three-stage charging mode:MPPT charging-lifting charging-floating charging.
●Photovoltaic three-stage charging mode:CC constant current-lifting charging-floating charging.
●12V/24V battery system automatically recognizes, or 12V/24V battery system automatically recognizes (Optional).
●RS485 communication can provide communication protocol to facitilate unified management and secondary development for customer.
●The controller operating parameters can be viewed and set through the mobile phone APP.( Optional )
●The controller has comprehensive protection functions such as overcharge, over discharge and overload;
●Lead-acid battery, ternary lithium battery, lithium iron phosphate, custom four battery types charging mode to choosing;
●The controller has various load control modes, the load has two outputs, and the output power and time can be set;
●The controller has wide adaptability, adaptive day and night;
System Parameter | |||||||||
Model | 600W30 | 1000W50 | 1200W60 | 1600W80 | 1600W80 | 2000W100 | 2400W120 | 3000W150 | |
System Rated Voltage | 12V(9V-16VDC) | 24V(18V-32VDC) | 48V(42V-60VDC) | ||||||
Solar Module | Voc | 27.6V | 55.2V | 105V | |||||
Vmp | >Vbat+1V | >Vbat+1V | >Vbat+1V | ||||||
Imp | 25A | 40A | 25A | 33A | 17A | 21A | 25A | 30A | |
Workable Power | 0W~300W | 0W~500W | 0W~600W | 0W~800W | 0W~800W | 0W~1000W | 0W~1200W | 0W~1500W | |
Wind Turbine | Rated Voltage | 12VAC（20.8VDC） | 24VAC(41.6VDC） | 48VAC（83.1VDC) | |||||
Rated Current | 25A | 40A | 25A | 33A | 17A | 21A | 25A | 30A | |
Workable Power | 0W~300W | 0W~500W | 0W~600W | 0W~800W | 0W~800W | 0W~1000W | 0W~1200W | 0W~1500W | |
DC Load | Out Power | 0W~180W | 0W~700W | 0W~1400W | |||||
Rated Voltage | 12VDC | 24VDC | 48VDC | ||||||
Current Max | 30A(15A*2) | 60A(30A*2) | 60A(30A*2) | ||||||
Conversion Efficiency | ﹥98% | ||||||||
Operation Mode | Default to streetlight mode | ||||||||
Environment | Temperature | 1) Working:-20℃～50℃; 2)Storage:-30℃～70℃ | |||||||
Humidity (°C) | 10% ～ 90% No condensation | ||||||||
Protection Grade | IP30 | ||||||||
Weight | G.W | 3.8KGS | 4.2KGS | 4.7KGS | |||||
Size | Packing | 36*30*13CM | 36*30*13CM | 39*33*13CM | |||||
Battery type setting
Similarly, other battery types and custom modes can be set by the same method as above. The digital serial number and battery type reference table are as follows:
Number type | type of battery | definition |
1 | Sealed | Lead-acid batteries |
2 | LiFePO4 | Lithium iron phosphate battery |
3 | LiNiCoMn | Ternary lithium battery |
4 | Custom | customize |
Time control parameter setting
Remark: In the same way, the time and space second time period T2, the second time period output power P2 percentage and the space time third time period T3, and the third time period output power P3 percentage can be set;
About: APP (WIFI or GPRS mode) connection device setting method, please refer to the corresponding APP manual;
State | The APP (WIFI or GPRS mode) is an optional accessory. The equipment can only use one mode for single communication, and cannot use two communication modes at the same time! |
