Features:
1. The color intelligent LCD screen displays the battery input battery voltage, output voltage, battery capacity, frequency 50Hz or 60Hz, and load capacity in real-time.
2. This product is equipped with fast charging dual USB ports, and an AC socket supports two USB charger ports (max. 4.2A) to work at the same time.
3. This product is designed to be lightweight, portable, and compact, making it easy to carry and store.
Specification:
Solar Panel 18W:
Power: 18W±5%
Dimensions: 420x280x2.5mm
DC output: 12V/1.5A
USB output: 5V/1.7A
Weight: 0.7kg
Type: Monocrystalline Solar Panel
Material: aluminum substrate
Output accessories: DC line + DC alligator clip
Power inverter 4000W:
Input voltage: DC 12V
Output voltage: AC 220V
The output frequency is: 50Hz
Max power: 4000W
Rate power: 300W (please ensure that the total rate power of the connected device is ≤300W).
Output waveform: modified sine wave
30A 12V 24V Automatic Solar Charge Controller PWM with LCD Controller and Dual USB
Charging current: 30A
Voltage: DC 12V / 24V automatic intelligent conversion
Display: LCD digital display
USB Charger Port: Dual USB 5V 2.1A
Working temperature: -35~+60
Maximum solar input: 12V battery, up to 23V
Float charge: 13.7V (default, adjustable)
Discharge stop: 10.7V (default, adjustable)
Discharge reconnection: 12.6V (default, adjustable)
Charging reconnect: 13V
Turn-on voltage: solar panel 8V (light delay)
Turn off voltage: solar panel 8V (light off delay)
USB output: 2 USB outputs, 5V/2.5A (MAX)
The wattage you choose depends on the wattage (or amperage) you want to run (find the power consumption by referring to the spec plate on the device or tool). We recommend that you buy a larger model than you think you need (at least 10% to 20% more than your maximum load).
Packaging list:
1*Inverter
1*Red and black battery clip
1*Cigarettelighter
1*Inverter manual
1*Solar controller
1*Controller manual
1*Solar panel
1*DC line
1*DC alligator clip
