Packing included:
As pictures show. Without battery. (Some necessary cables need to be prepared by yourself for the whole set)
Solar panel :
Specification:
Name: Solar Charging Panel
Battery type: monocrystalline silicon solar cells
Number of cells: 36pcs
Rated power: 100W
Module efficiency: 20.3%
Power tolerance: ±5
Open circuit voltage: 21V
Short circuit current: 6A
Maximum power point operating voltage: 18v
Maximum power point operating current: 5.5A
Irradiation rate: 100%
Packaging material: PET
Chemical Type: EVA
Junction Box: MCA
Connector: MC4
Size: 1050*540mm
Controller:
Voltage: DC 12V / 24V
Rated current: 60A
Maximum photovoltaic voltage: 50V
Display: LCD screen
Self-consumption: <10MA
Overcharge protection: 14.4V / 28.8V
Overcharge Float charge: 13.7V / 27.4V
Charge recovery voltage: 12.6V / 25.2V
Over discharge protection: 10.7V / 21.4V
Over discharge recovery: 12.6V / 25.2V
Dual USB output: 5V / 2A (charge mobile phone, iPad, etc.)
Working temperature: -35 ℃ -60 ℃
Power inverter:
-Input voltage: DC 12V for car
-Output voltage : AC 220V (210~230V)
-Output frequency: 50Hz
-Peaks Power : 8000W
-Rated power: 1300W (Please make sure that the total rated power of the connected devices is ≤ 1300W)
-Product size: 33X6X10.3cm
-Maximum Active Surge Rating (less than 1 second) :8000W
-Maximum AC Current per socket :8.33Ampere
-Output Waveform: True/pure sine wave (<3% THD)
Efficiency: 90≥%
-No Load Current Draw (DC side) <0.6 A
-8 Safety Protection Function:
Reverse polarity protection, Low input voltage protection, High input voltage protection, Over-current protection, Short circuit protection, Over temperature protection, Overload protection, Internal fuses
Features:
* [Pure Sine Wave] Converts 12V DC to AC 220V household wall power with continuous 1300W output (8000W surge capability) with 1 AC receptacles, one LED Voltage display, high current DC terminals and two LED work lights. (Please make sure that the total rated power of the connected devices is ≤ 1300W).
* [Strong and Durable] Aluminum alloy housing provides advanced protection from drops and bumps.
* [LED Green&Red Work Lights] When inverter work normal, the two green LED Lights work, but when it is on protection status, the Red Led Lights will light up.
* [LED Voltage Screen display] LED Display shows the battery Input real-time voltage and remind you to charge your battery according to the low voltage.
* [Widely Applications ] Great for gift,charging TV, washing machine, air conditioner, refrigerant, Microwave and big power appliance. These can only operate a few 220V loads without interference. It can also use with in the car or solar system.
* [Car Becomes RV] With our car power inverter, you can use most of home appliances in your car in the open air, such a watching TV, playing games, give you the experience like being in an RV.
* [Silent Intelligent Cooling Fan] Equipped with silent cooling fan, it will automatically runs at different speed according to power load (watt) load and temperature for dissipating heat and reducing working noise. There is a temperature sensor built in the inverter. When it is over 45℃, the fans will work automatically. When the temperature is over 75 ℃-80 ℃, the inverter will be in protection mode till it cool down.
NOTE:(Pure Sine Wave Inverter suitable for sensitive load appliances, such as refrigerators, air conditioners, coffee machines, bread machines, induction cookers, etc.)
Battery Usage Time Calculation:
1)The working time of inverter, it is depend on the battery power and load power.
2)Formula: Working time (hours)= Battery Capacity X Battery Voltage X 0.8X0.9/Load Power
3) For example, the battery of 12V 60A is supplied to a 220V 100W bulb.
The working time is = 12(V) X 60(AH) X 0.8 X 0.9/100(W)=5.18(hours)
(Note: 0.8 is battery discharge coefficient, 0.9 is inverter conversion efficiency)
