Product Description
Specification
Specification
| Battery | Battery | Lithium ion (Li(NiCoMn)O2) |
| Life Cycles | 300 Deep Cycles to 80% Capacity | |
| Capacity | 518Wh | |
| BMS | Charge Cut-off Voltage | 24.9V |
| Charge Recovery Voltage | 24V | |
| Discharge Cut-off Voltage | 16.2V | |
| Discharge Recovery Voltage | 18V | |
| Max Charge Current | 40A | |
| Max. Continuous Discharge Current | 33.18A | |
| Max. Instant Discharge Current | 100.5A,≤1S | |
| Charge Temperature | 0~40°C | |
| Discharge Temperature | -20~60°C | |
| Discharge Monitoring | Support | |
| Charge Monitoring | Support | |
| Inverter | Input Voltage | 16.2V~25.2V |
| Output Voltage | 115~120V,60Hz(US); 230V-240V,50Hz(AUS) | |
| Max. Output Wattage | 500W | |
| Conversion Efficiency | ≥0.93 | |
| Max. Starting Watts | 1000W≤1S | |
| Output | AC | 500W |
| USB-A (1) | 5V/3.0A; 9V/2.0A;12V/1.5A (Quick Charge 3.0; 18W) | |
| USB-A (2) | 5V/2.4A (12W) | |
| USB-C (1) | 5V/3.0A; 9V/3.0A; 12V/3.0A; 15V/3.0A; 20V/3.0A (60W Bi-directional) | |
| USB-C (2) | 5V/3.0A; 9V/2.0A; 12V/1.5A (18W) | |
| CIG | 12V/8A; 100W | |
| Input | DC Input | 120W |
| Anderson | 30A | |
| USB-C (1) | 60W (Bi-directional) | |
| Lighting | LED Light | 500LM |
| HCI | Display | 3.5" LCD Display |
