Solar Panel Multimeter Solar Panel Tester LCD Display EY800W 3rd Generation Handheld for Photovoltaic Panel
Feature: Specification: Item Type: Solar Panel Multimeter
2. Multiple Detection: Solar panel MPPT tester has AUTO MPPT detection and manual MPPT detection. No additional power supply required
3. Safety Assurance: Solar panel MPPT meter has over voltage, over temperature, over current protection, safe and reliable.
4. Reverse Connection And Power Protection: MPPT tester has solar panel reverse connection protection and over rated power protection.
5. Durable Material: The LCD MPPT solar panel multimeter is made of high quality ABS material and is robust and corrosion resistant for a long service life.
Material: ABS
Size: Approx. 165x80x30mm / 6.5x3.1x1.2in
Model: EY800W 3rd Generation
Power: 5-800W
Voltage: 12-60V
Current: 0-35A
Power mode: Solar Panel Power
Features: LCD Display Function
Target Audience: Solar Panel Manufacturers, Solar Panel Distributors, Solar Panel Installers, Solar Panel Users, Solar Panel FansTROUBLESHOOTING ERROR CAUSE EXPLANATION No display Reverse connection protection Please check the input polarity Display over power Over rated power Using within the rated power range of the instrument Display over temperature Over temperature protection To be used after cooling Display over voltage Over voltage protection Using within the rated voltage range of the instrument Display over current Over current protection Using within the rated current range of the instrument
Package List:
x Solar Panel Multimeter
2 x Connection Cable
2 x Clip Cable
x English Manual
x EVA Kit
Note:
. Manual measurement please allow some errors.2. Please be sure to use this product within the rated voltage & current power range.3. Please be sure to disconnect the solar panel from other equipment or loads before testing.How to use:
I. Automatic MPPT test method: When the [AUTO MPPT] test button is pressed, the multimeter will automatically adjust the test interval time according to the current power value and refresh the digital display.Example: When the solar panel power is 100W, the display will be refreshed every 5S; when the solar panel power is 350W, the display will be refreshed every 15 seconds. When the solar panel power is 700W, the display will be refreshed every 30 seconds.II. Manual MPPT test method: When the [manual MPPT] test button is pressed, the multimeter starts scanning the maximum power point, refreshes the digital display, and keeps the last test result.III. Open circuit voltage detection method: When the multimeter is working, the LCD will display the open circuit voltage of the solar panel in real time.
