Affordable Wholesale Solar Micro Inverter Grid Tie 18‑60V High Conversion Rate Waterproof Grid Tie Micro Inverter for Generation Systems AC220V

SKU: 1005004803880121
Safe Payment Guarantee:


Solar Micro Inverter Grid Tie 18‑60V High Conversion Rate Waterproof Grid Tie Micro Inverter for Generation Systems AC220V


Feature:

1. Working Principle: A solar micro inverter is a device that converts the DC of a solar panel into an AC. It is small in size and capacity and is often used in small solar systems.
2. High Conversion Rate: The grid connected inverter has high conversion efficiency, the highest conversion efficiency can attain 92%, and the use efficiency is improved.
3. Simple Operation: The grid connected inverter needs to be connected to the grid before it can be used, and the simple operation is convenient for your use.
4. Aluminum Alloy Material: Micro inverter is made of aluminum alloy material, which is wear resistant and durable, and can be used for a long time.
5. Note: This inverter can only be used with solar panels, not with batteries, please use it with caution.


Specification:



Item Type: Solar Micro Inverter Grid Tie
Material: Aluminum Alloy
Product Series: PVGS300 500 Series
Input Data(DC,PV):
Number of Input MC4 Connector:1 set
MPPT Voltage Range: 28V-55V
Operation Voltage Range: 18V-60V
Maximum Input Voltage : 60V
Startup Voltage : 18V
Output Data(AC):
Single Phase Grid Type : 230V
Nominal Output Voltage: 230VAC
Default Output Voltage Range: at 230VAC : 180V-280V
Nominal Output Frequency: 60Hz
Default Output Frequency Range: at 60Hz : 57.5Hz-62.5Hz
Power Factor: >0.99
Total Harmonic Distortion : THD <5%
Efficiency:
Nominal MPPT Efficiency MPPT: 99.90%
Night Power Consumption: <700mW
Mechanical Data:
Operating Ambient Temperature Range: -40°C to +65°C
Storage Temperature Range: -40°C to +85°C
Waterproof Grade : IP55
Cooling Mode: Natural Convection, No Fans
Other Features:
Transformer Design: High Frequency Transformers, Galvanically Isolated
Integrated Ground: Equipment ground is provided by the PE in the AC cable. No additional ground is required.
Protection Functions: Isolated Island, Voltage, Frequency, Temperature, Current etc.





Package List:

1 x Solar Micro Inverter

1 x User Manual

1 x Connecting Line



How to use: Before installing the microinverter, please check if the grid voltage and PV module voltage match the input and output voltage levels marked on the label attached to the microinverter housing, if not, please stop the installation, otherwise the microinverter may be damaged. 1. (Install the microinverter on the stand: a. marked the position of the microinverter on the stand according to the distance from the PV module junction box or other obstacles, etc. b. Use the tools recommended by the stand supplier to fix each microinverter to the designated position.) 2. (Connect the AC cables of all microinverters in turn and connect them (Fire wire brown, null wire blue, Ground wire yellow green) to the AC main cable. Please note: The number of connections per branch should not exceed the maximum number of currents) 3. (Connect the PV module to the micro inverter. (Please note: The PV module voltage must not exceed the maximum input voltage of the inverter.) 4. (Install the AC branch waterproof junction box and connect the AC bus to the junction box, and connect the AC branch junction box to the grid connection point.) 5(Check again that all micro inverters, connectors and cables are correctly and well connected.) 6.(Close each branch AC circuit breaker in turn.) 7(Close the main circuit breaker, your power system will start to generate electricity after waiting for 3 seconds.)
