Smart Microinverter Feature
Please attentiont,this inverter is designed for solar panels,which can be suitable for 24V (48 cells), 30V (60 cells) and 36V (72 cells). If customers want to use this inverter for battery, please connect 36V battery for this inverter. If your battery is 24V, you can choose 10.8-30VDC version. However, we still suggest customers don't use battery for this inverter, it will influence product life-span.
1. Three input voltage range, suitable for different solar panels.
1).18V or 36 cells solar panels, Vmp is 18-21V and Voc is 20-24V.
2).24V or 60 cells solar panels, Vmp is 26-30V and Voc is 34-38V.
3).36V or 72 cells solar panels, Vmp is 35-39V and Voc is 42-46V.
2. Support for small power wind turbine using grid power.
3. Creative MPPT tech makes efficiency higher than 99%. Reaction more sensitive and MPPT locking faster.
4. Adopting high-frequency isolation transformer, high efficiency, and high security.
5. Creative circuit design and imported industrial electronic components make application efficiency higher and performance more stable.
6. Parallel modular components design (stacking use) is convenient for systems setting, flexible combination and system scalability.
Advantages of Smart Microinverter
1. Unique circuit design, choice of import industrial electronic components, higher efficiency, more
stable performance.
2. MPPT technology, efficiency more than 99%, faster and more sensitive reaction, more
reliable.
3. Parallel type design for DC input and modularization design for inverter, small volume, distributed
installation, easy for system configuration, flexible for combination, strong expansibility of system.
4. Adopting high-frequency isolation transformer type, high efficiency, and high security.
5. Perfect electrical protection function.
6. Aluminum alloy housing, not rust, heat-resisting and cold-resistant as well as anti-corrosion.
7. Getting electronic circuit design, appearance design and other core technology patents.
Power | 1000W or 1300W | |
Solar panels | ≥1000W or ≥1300W | |
DC MAX input | 1200W or 1400W | |
The Voltage of Matched solar panel | Vmp: 18-21V, Voc: 20-24V | Vmp: 26-39V, Voc: 34-45V |
DC input range | 10.8-30V | 20-45 |
MPPT Voltage | 15-23VDC | 24-36VDC |
DC MAX current | 80A | 50A |
AC MAX output | 1100W or 1400W | |
AC output range | 120VAC(90-140VAC) or 230VAC(190-260VAC) | |
Frequency range | 50Hz/60Hz | |
Power Factor | >97.5% | |
THD | <5% | |
Phase Shift | <1% | |
Peak Efficiency/110V | 82% | 87% |
Stable Efficiency /110V | 79% | 84% |
Peak Efficiency/220V | 82% | 87% |
Stable Efficiency/220V | 80% | 85% |
Protection | Islanding; Short-circuit; converse connection; Low Voltage; Over Voltage; Over temperature Protection | |
Work Temperature | ‘-25°C-80°C | |
Work Humidity | 0%~90%RH non-condensing | |
Grade of Waterproof | Indoor design | |
Show | 1 Red and 1 Green | |
Cooling | Fan | |
Stand-by Power | 2-3W | |
EMC | EN61000-6-3:2007 EN61000-6-1:2007 | |
Grid Disturbance | EN 50178+EN 62109-1+VDE0126-1-12 | |
Grid Detection | DIN VDE 1026 UL1741 | |
Certificate | CE | |
Net Weigtht | 2.0kgs/pc | |
Gross Weight | 2.7kgs/pc | |
Inner Box (LxWxH) | 31x16.5x5.3cm | |
Carton (LxWxH) | 42x40.5x24.2cm | |
