big 5000W Wind Solar Hybrid Charge Controller, 12V 24V 48V AUTO Match, MPPT Charge for Solar Panel Wind Turbine, for Lithium Lea
Product Description:
Product Introduction
This
model is special designed for hybrid wind solar power system charge for
low-power street lamp, monitoring etc. system. And it is workable for
Lithium , GEL, Lead-acid battery with full charge and discharge
protection. Large size LCD screen is convenient for parameter(from
solar, wind and battery) query and adjustment but low power consumption.
It can be flexibly installed in cruise ships, RVs, and land indoors.
Powerful functions and light size but very good heat dissipation are its
outstanding features.
Perfect Protection
Solar
Reversed Charging protection，Battery open circuit protection、battery
anti-reverse connection protection protection、Over current and over
voltage auto brake protection、Over load protection,etc.
High performance and stable chip control;
1. Automatically match with 12V/24V48V sealed battery voltage;
2. Workable for battery: 1. Sealed( Lead-acid, GEL); 2. Lithium(Ternary Lithium, Lithium iron);
3. LCD displays voltage and current of wind, solar and load parameter;
4. The inner circuit board of the controller is sprayed to prevent dust, moisture and static electricity.
5. Wind adopts MPPT boost charging; external dump-load resistance, intelligent disconnection of Solar charging.
Product Parameter:
1. System Parameter |
||||||||||
Model |
1600W0808 |
2000W1010 |
2400W1212 |
2700W1512 |
3000W1515 |
3500W2015 |
4000W2020 |
4500W2520 |
5000W2525 |
|
System Rated Voltage |
12V/24V(Auto) or 24V/48V(Auto)------Regular model |
12V/24V(Auto) or 24/48V(Auto)-Customized model |
||||||||
Wind Turbine |
Rated Voltage |
12VAC / 24VAC / 48VAC |
12VAC / 24VAC / 48VAC |
|||||||
MPPT(Boost Up) |
7VAC(12V System ) / 17VAC(24V System ) / 34VAC(48V System) |
17VAC(24V System ) / 34VAC(48V System) |
||||||||
Max Current |
45A（12V）34A (24V) 17A (48V) |
55A（12V）42A (24V) 21A (48V) |
66A（12V）50A (24V) 25A (48V) |
83A（12V）63A (24V) 32A (48V) |
83A（12V） 63A (24V) 32A (48V) |
100A（12V） 83A (24V) 42A (48V) |
100A（12V） 83A (24V) 42A (48V) |
138A（12V） 104A (24V) 52A (48V) |
138A（12V） 104A (24V) 52A (48V) |
|
Workable Power |
0~800W |
0~1000W |
0~1200W |
0~1500W |
0~1500W |
0~2000W |
0~2000W |
0~2500W |
0~2500W |
|
Brake |
Start Voltage |
15VAC(21VDC) / 30VAC(42VDC)/60VAC(84VDC) |
30VAC(42VDC)/60VAC(84VDC) |
|||||||
Recover Voltage |
13.5VAC(12V System )/27VAC(24V System )/54VAC(48V System ) |
27VAC(24V System )/54VAC(48V System ) |
||||||||
Solar Module |
Voc |
24V~27.6VDC(12V System) 36V~55.2VDC(24V System) 72V~105VDC(48V System) |
36V~55.2VDC(24V System) 72V~105VDC(48V System) |
|||||||
Vmp |
15V~22VDC(12V System) 30V~44VDC(24V System) 60V~88VDC(48V System) |
30V~44VDC(24V System) 60V~88VDC(48V System) |
||||||||
Charge Current(MAX) |
45A（12V）34A (24V) 17A (48V) |
55A（12V）42A (24V) 21A (48V) |
66A（12V）50A (24V) 25A (48V) |
66A（12V）50A (24V) 25A (48V) |
83A（12V）63A (24V) 32A (48V) |
83A（12V） 63A (24V) 32A (48V) |
100A（12V） 83A (24V) 42A (48V) |
100A（12V） 83A (24V) 42A (48V) |
138A（12V） 104A (24V) 52A (48V) |
|
Workable Power |
0~800W |
0~1000W |
0~1200W |
0~1200W |
0~1500W |
0~1500W |
0~2000W |
0~2000W |
0~2500W |
|
DC Load |
Out Put Power |
0~120W(12VSystem)/0~240W(24VSystem)/0~240W(24VSystem) |
0~240W(24VSystem)/0~240W(24VSystem) |
|||||||
Rated Voltage |
12VDC / 24VDC / 48VDC |
12VDC / 24VDC / 48VDC |
||||||||
Max Current |
10A |
10A |
||||||||
Environment |
Temperature |
1) Working:-20℃～55℃; 2)Storage:-40℃～80℃ |
||||||||
Humidity (°C) |
10%～90% No condensation |
|||||||||
Protection Grade |
IP30 |
|||||||||
Others |
Conversion Efficiency |
﹥98% |
||||||||
Operation Mode |
Default to streetlight mode |
|||||||||
Weight |
N.W: 3KGS/G.W: 4KGS |
|||||||||
Packing Size |
Product size：171*145*69mm/PK Size: 200*350*120mm |
|||||||||
2. Battery Parameter |
|||||||
System Voltage |
12V |
24V |
48V |
||||
(b0)Customer Type |
|||||||
FULL |
Over Charge |
14.7V |
Adjustable |
29.4V |
Adjustable |
58.8V |
Adjustable |
LOW |
Over Discharge |
10.2V |
Adjustable |
20.4V |
Adjustable |
40.8V |
Adjustable |
RLOW |
Over Discharge Return |
11.5V |
Adjustable |
23.0V |
Adjustable |
46.0V |
Adjustable |
Special Note: No one-key restore function, please do not modify preset parameters. |
|||||||
(b1)Lead acid battery |
|||||||
FULL |
Over Charge |
14.4V |
Default |
28.8V |
Default |
57.6V |
Default |
LOW |
Over Discharge |
10.2V |
Default |
20.4V |
Default |
40.8V |
Default |
RLOW |
Over Discharge Return |
11.5V |
Default |
23.0V |
Default |
46.0V |
Default |
(b2)Ternary lithium battery |
|||||||
FULL |
Over Charge |
12.6V |
Default |
25.2V |
Default |
50.4V |
Default |
LOW |
Over Discharge |
9.0V |
Default |
18.0V |
Default |
36.0V |
Default |
RLOW |
Over Discharge Return |
11.0V |
Default |
22.0V |
Default |
44.0V |
Default |
(b3)Lithium Iron Phosphate LiFePO4 |
|||||||
FULL |
Over Charge |
14.4V |
Default |
28.8V |
Default |
57.6V |
Default |
LOW |
Over Discharge |
10.0V |
Default |
20.0V |
Default |
40.0V |
Default |
RLOW |
Over Discharge Return |
11.0V |
Default |
22.0V |
Default |
44.0V |
Default |
Note:to know about more instruction and model, please contact us for FREE beautifully illustrated user manual(with various hybrid contoller product catalogue)
