Products Description
DPiL SERIES SPECIFICATIONS
OUTPUT
CHARGING INPUT
| Model | DP500iL | DP1000iL | DP1500iL | DP2000iL | DP2500iL | ||||
| Rated Power | 500VA | 1000VA | 1500VA | 2000VA | 2500VA | ||||
| Peak Power | 1000VA | 2000VA | 3000VA | 4000VA | 5000VA | ||||
| Dimensions | 530mm (20.9 in)X320mm (12.6 in)X430mm (16.9 in) | ||||||||
| Weight |
27kg (60 lbs) |
34kg (75 lbs) |
34kg (75 lbs) |
36kg (79 lbs) |
41kg (90 lbs) |
||||
| Battery Type | LiFePO4 | ||||||||
| Battery Capacity |
1280Wh, 100Ah (12.8V) |
2048Wh, 80Ah(25.6V) |
2688Wh, 105Ah (25.6V) |
||||||
| Battery Cycle Life | >2000 cycles | ||||||||
| AC Output | Output Waveform | Pure-Sine Wave, THD<3% |
| Rated Voltage | 100/110/120/220/230/240V | |
| Rated Frequency | 60/50Hz | |
| DC Output | Anderson SB50(1) | 12V/33A |
| Cigarette Lighter | 12V/10A | |
| 6mm Port | 12V/6A | |
| USB | 5V/2A/1A |
| Model | DP500iL | DP1000iL | DP1500iL | DP2000iL | DP2500iL | |||
| AC | Wall Outlet | 100~120V / 200~240V, Max. 300W, 5.5 hours fully charged | 100~120V / 200~240V, Max. 300W, 8.5 hours fully charged |
100~120V / 200~240V, Max. 300W, 12 hours fully charged |
||||
| Solar | MPPT Control System | 18~70V, Max. 300W, 5.5 hours fully charged | 36~140V, Max. 600W, 4 hours fully charged | 36~140V, Max. 600W, 5 hours fully charged | ||||
| Car | 8mm Port |
12~15V / 24~30V, Max.120W 15 hours fully charged |
12~15V / 24~30V, Max.160W 18 hours fully charged |
12~15V / 24~30V, Max.160W 24 hours fully charged |
||||
